Computer Lab: Matrix Machine Use the matrix machine from IDE (Lab I5) to analyze each trans formation from $\mathbb{R}^2$ to $\mathbb{R}^2$ in Problems 83-88, and answer the following questions.
(a) Which vectors are not moved by the transformation?
(b) Which nonzero vectors do not have their direction changed?
(c) Which vectors do not have their magnitude changed?
(d) Which vectors map onto the origin? This set is called the nullspace of the transformation.
(e) Which vectors, if any, map onto $\left[\begin{array}{l}1 \\ 0\end{array}\right]$ ?
(f) Find the image of the transformation, and state whether it is all of $\mathbb{R}^2$ or a subset.
Matrix Machine Enter a matrix, then point/click to choose or change a vector; simultaneously you will see its transformation by the vector.
$\left[\begin{array}{ll}1 & 2 \\ 1 & 0\end{array}\right]$

Key Concepts

Nullspace (Kernel) of a Transformation

The nullspace, or kernel, of a transformation is the set of all vectors that are mapped to the zero vector. It is a subspace of the domain and provides insights into the solution set of homogeneous linear equations, as well as the invertibility of the transformation.

Image (Range) of a Transformation

The image, or range, of a transformation is the set of all vectors that can be produced by applying the transformation to vectors in the domain. Determining the image helps to understand how completely the transformation covers the codomain, which in turn relates to concepts of surjectivity.

Norm Preservation

Norm or magnitude preservation occurs when a transformation does not change the length of a vector. Identifying vectors that maintain their magnitude under a transformation involves checking whether the transformation satisfies ||T(v)|| = ||v||. Such properties are important in the context of rotations and reflections.

Eigenvectors and Eigenvalues

Eigenvectors are nonzero vectors that change only in scale (and not in direction) when a linear transformation is applied; they satisfy the equation T(v) = ?v, where ? is an eigenvalue. This concept is crucial for understanding directional invariance within linear transformations.

Fixed Vectors

Fixed vectors are those that remain unchanged when a transformation is applied, meaning that for a given vector v, the transformation satisfies T(v) = v. Identifying these vectors involves solving the equation (T - I)v = 0, where I is the identity matrix.

Matrix Representation

Matrices provide a concrete way to represent linear transformations. A matrix acts on vectors through multiplication, and its entries dictate how vectors are scaled, rotated, or otherwise altered. Studying the matrix helps in identifying various properties of the transformation such as fixed points, changes in magnitude, and direction.

Linear Transformations

A linear transformation is a function between two vector spaces that preserves vector addition and scalar multiplication. It can always be represented by a matrix, and understanding its behavior is central to linear algebra. Analyzing such a transformation involves determining how it maps vectors from the domain to the codomain.
