Consider a cogeneration system operating as illustrated in Fig. 8.14. The steam generator provides a $10^{6} \mathrm{~kg} / \mathrm{h}$ of steam at $8 \mathrm{MPa}, 480^{\circ} \mathrm{C}$, of which $4 \times 10^{5} \mathrm{~kg} / \mathrm{h}$ is extracted between the first and second turbine stages at $1 \mathrm{MPa}$ and diverted to a process heating load. Condensate returns from the process heating load at $0.95 \mathrm{MPa}, 120^{\circ} \mathrm{C}$ and is mixed with liquid exiting the lower-pressure pump at $0.95 \mathrm{MPa}$. The entire flow is then pumped to the steam generator pressure. Saturated liquid at $8 \mathrm{kPa}$ leaves the condenser. The turbine stages and the pumps operate with isentropic efficiencies of 86 and $80 \%$, respectively. Determine (a) the heating load, in $\mathrm{kJ} / \mathrm{h}$. (b) the power developed by the turbine, in $\mathrm{kW}$. (c) the rate of heat transfer to the working fluid passing through the steam generator, in $\mathrm{kJ} / \mathrm{h}$.

Consider a cogeneration system operating as illustrated in Fig. 8.14. The steam generator provides a $10^{6} \mathrm{~kg} / \mathrm{h}$ of steam at $8 \mathrm{MPa}, 480^{\circ} \mathrm{C}$, of which $4 \times 10^{5} \mathrm{~kg} / \mathrm{h}$ is extracted between the first and second turbine stages at $1 \mathrm{MPa}$ and diverted to a process heating load. Condensate returns from the process heating load at $0.95 \mathrm{MPa}, 120^{\circ} \mathrm{C}$ and is mixed with liquid exiting the lower-pressure pump at $0.95 \mathrm{MPa}$. The entire flow is then pumped to the steam generator pressure. Saturated liquid at $8 \mathrm{kPa}$ leaves the condenser. The turbine stages and the pumps operate with isentropic efficiencies of 86 and $80 \%$, respectively. Determine
(a) the heating load, in $\mathrm{kJ} / \mathrm{h}$.
(b) the power developed by the turbine, in $\mathrm{kW}$. (c) the rate of heat transfer to the working fluid passing through the steam generator, in $\mathrm{kJ} / \mathrm{h}$.

Key Concepts

Rankine Cycle

The Rankine cycle is the fundamental thermodynamic cycle used in steam power plants, describing the process by which water is converted into steam in a boiler, expanded through a turbine to produce work, condensed back into liquid in a condenser, and then pumped back to the boiler. It is critical to understand the energy transformations and efficiency losses at each stage of the cycle in order to analyze and optimize power generation systems.

Cogeneration

Cogeneration, also known as combined heat and power (CHP), is the simultaneous production of electricity and useful thermal energy from a single fuel source. This concept is essential in systems where waste heat from power generation is recovered and utilized for heating, enhancing overall energy efficiency and reducing energy costs.

Energy and Exergy Analysis

Energy balance, along with exergy analysis, involves applying the first law of thermodynamics to quantify the energy inputs, outputs, and losses in a system. This analysis is crucial for determining key performance parameters such as heating loads, work outputs from turbines, and heat transfers in components like steam generators, thereby allowing engineers to assess and improve system efficiency.

Isentropic Efficiency

Isentropic efficiency is a measure of the performance of turbomachinery, comparing the actual work output or input to the ideal work output or input in an isentropic (reversible adiabatic) process. In turbines and pumps, this efficiency indicates how closely the real process approximates the ideal assumption and helps in quantifying the losses due to irreversibilities during expansion or compression.

State Properties and Phase Changes

Understanding the thermodynamic properties of the working fluid, such as enthalpy, pressure, and temperature, is crucial in steam power cycles, especially when dealing with processes like steam extraction, condensation, and superheating. Correct identification of phase changes and property variations of water/steam is essential for accurate energy balance calculations and system design.
