Consider a steam power plant that operates on a reheat Rankine cycle and has a net power output of $80 \mathrm{MW}$ Steam enters the high-pressure turbine at $10 \mathrm{MPa}$ and $500^{\circ} \mathrm{C}$ and the low-pressure turbine at $1 \mathrm{MPa}$ and $500^{\circ} \mathrm{C}$. Steam leaves the condenser as a saturated liquid at a pressure of $10 \mathrm{kPa} .$ The isentropic efficiency of the turbine is 80 percent, and that of the pump is 95 percent. Show the cycle on a $T-s$ diagram with respect to saturation lines, and determine (a) the quality (or temperature, if superheated) of the steam at the turbine exit, $(b)$ the thermal efficiency of the cycle, and $(c)$ the mass flow rate of the steam.

Consider a steam power plant that operates on a reheat Rankine cycle and has a net power output of $80 \mathrm{MW}$ Steam enters the high-pressure turbine at $10 \mathrm{MPa}$ and $500^{\circ} \mathrm{C}$ and the low-pressure turbine at $1 \mathrm{MPa}$ and $500^{\circ} \mathrm{C}$. Steam leaves the condenser as a saturated liquid at a pressure of $10 \mathrm{kPa} .$ The isentropic efficiency of the turbine is 80 percent, and that of the pump is 95 percent. Show the cycle on a $T-s$ diagram with respect to saturation lines, and determine
(a) the quality (or temperature, if superheated) of the steam at the turbine exit, $(b)$ the thermal efficiency of the cycle, and $(c)$ the mass flow rate of the steam.

Key Concepts

Rankine Cycle

The Rankine cycle is a fundamental thermodynamic cycle used in steam power plants to generate electricity. It involves the processes of heat addition in a boiler, the expansion of steam in a turbine to produce work, heat rejection in a condenser, and the liquid water's pressurization by a pump. Its analysis is crucial in determining system efficiency and optimizing operational parameters.

Reheat Process

The reheat process is incorporated in a Rankine cycle to improve efficiency and prevent moisture-related damage in the turbine. In this process, after partial expansion in the high-pressure turbine, steam is reheated before being sent into a low-pressure turbine, thus maintaining a higher average temperature during heat addition and reducing the moisture content at the turbine exit.

Temperature-Entropy (T-s) Diagram

A T-s diagram is a graphical tool used to represent the changes in the state of a working fluid during thermodynamic processes, particularly plotting temperature against entropy. This diagram is especially useful in visualizing the different stages of the Rankine cycle, including heat addition, reheat, expansion, heat rejection, and compression, helping to identify areas for efficiency improvement.

Isentropic Efficiency

Isentropic efficiency is a metric used to compare the actual performance of turbines and pumps to the ideal, reversible (isentropic) process. It quantifies the losses due to irreversibilities in the expansion or compression processes and is critical for accurately predicting the work output of turbines and the work input for pumps in the cycle.

Steam Quality

Steam quality refers to the fraction of vapor in a steam-water mixture and is an important parameter in the analysis of steam turbines. It indicates whether the steam is dry or contains moisture, and maintaining proper quality is essential for ensuring efficient energy extraction and preventing turbine blade erosion.

Thermal Efficiency

Thermal efficiency is the ratio of the net work output of a cycle to the heat input, serving as a measure of how effectively a power plant converts heat into useful work. Evaluating thermal efficiency helps in understanding the performance of the cycle and in implementing design improvements to reduce fuel consumption and emissions.

Mass Flow Rate

Mass flow rate is the quantity of working fluid moving through the system per unit time, which is a critical parameter in scaling the power output and determining the overall performance of a power plant. Accurate determination of mass flow rate is necessary for balancing the energy and mass in the cycle and ensuring that the plant meets its designed power output.

Transcript

00:01 In this problem, let's see here, we got another, not an idea, a reheat ranking cycle, but not ideal.

00:10 And so in this case, we have a high pressure side up here at 10 megapascals.

00:19 Low pressure side were given this time of 10 kilpascals.

00:25 We're actually told what the power output is, and that's 80 megawatts.

00:29 The temperature at, let's see here, i think i wrote that wrong again.

00:38 T3 and t5, not t4.

00:43 So up here, we are at 500 degrees celsius.

00:48 The pressure here is a 1 megapa scale.

00:53 We're given that.

00:55 The efficiency of the turbine is now 80%, and that of the pump is 95%.

01:00 So at 3, we can get the entropy and the entropy at 3, because we know the pressure and temperature.

01:11 So the entropy at 4 prime, straight down here, is the same as entropy at 3.

01:17 So we can get the isotropic enthalpy at 4.

01:23 And from that, and from these two things, and the turbine efficiency, we can have find the enthalpy for the actual entropy.

01:36 Now at 5, we have pressure and temperature, so we can get enthalpy and entropy.

01:43 And then we know the isotropic case, the entropy at 6 is the same as entropy of 5.

01:49 So that would give us a quality factor in the isotropic case of 94 .9%.

01:56 And then the enthalpy in the is in the isentropic case would be 2 ,461 kilojoules per kilogram.

02:05 Now we can then use this and this and our efficiency to get the enthop the actual entropy at six and that is 2 ,665 kilojoules per kilogram.

02:19 Now it turns out and i drew this wrong and that is actually a saturated vapor...
