Consider a system consisting of a motor driving a load. The motor has the torquespeed characteristic shown in Figure $\mathrm{P} 16.14$ The load is a fan requiring a torque given by $$T_{\text {load }}=K \omega_{m}^{2}$$ At n speed of $n=1000 \mathrm{rpm},$ the power absorbed by the load is 0.75 hp. Detcrmine the specd of the system in radians per second and the power delivered to the fan in watts Convert your answers to rpm and horscpower.

Consider a system consisting of a motor driving a load. The motor has the torquespeed characteristic shown in Figure $\mathrm{P} 16.14$ The load is a fan requiring a torque given by
$$T_{\text {load }}=K \omega_{m}^{2}$$
At n speed of $n=1000 \mathrm{rpm},$ the power absorbed by the load is 0.75 hp. Detcrmine the specd of the system in radians per second and the power delivered to the fan in watts Convert your answers to rpm and horscpower.

Key Concepts

Motor Torque-Speed Characteristic

This concept describes how the motor’s torque output varies with speed. Generally, the motor will have a specific curve relating torque to angular velocity, which is crucial for determining how the motor behaves under load and ensuring that the motor and load are properly matched in performance.

Load Characteristics

The load characteristics define the relationship between the torque required by the load and the motor’s angular speed. In cases like fans, the torque is often proportional to the square of the angular velocity, meaning that as speed increases, the required torque increases rapidly. Understanding this relationship is vital for accurate system design and analysis.

Rotational Power Relationships

Rotational power is the product of torque and angular speed, expressed as P = T · ? when using consistent units. This relationship allows for the calculation of power delivered to or absorbed by components in rotational systems and is fundamental when analyzing mechanical systems that convert electrical energy into mechanical work.

Unit Conversions

Many engineering problems require converting units to maintain consistency and clarity. Key unit conversions in these systems include changing rotational speed from revolutions per minute (rpm) to radians per second (rad/s) and converting power units from horsepower (hp) to watts (W). Accurate conversions are essential for correct calculations and analysis.

System Equilibrium

System equilibrium in the context of motor-load systems is achieved when the motor torque equals the load torque at a particular speed. This balance point determines the operating speed of the system and is crucial for analyzing performance, stability, and ensuring that the motor is neither overpowered nor overloaded by the load.
