Consider air at room temperature moving through a pipe at a pressure low enough so that the mean free path is much longer than the diameter of the pipe. Estimate the net flux of molecules in the steady state resulting from a given pressure gradient in the pipe. Use this result to calculate how long it will take to reduce the pressure in a tank of 100 litres volume from $10^{-5} \mathrm{~mm}$ of Hg to $10^{-8} \mathrm{~mm}$ of Hg , if it is connected to a perfect vacuum through a pipe one meter long and 10 cm in diameter. Assume that the outgassing from the walls of the tank and pipe can be neglected.

Key Concepts

Vacuum System Conductance

Conductance in a vacuum system quantifies the ability of a piping or component to carry gas from one region to another. In free molecular flow, conductance depends on factors such as the geometry of the pipe (length, diameter) and the thermal properties of the gas. It is a key parameter for estimating the rate at which gas can be removed from a chamber or tank.

Pressure Gradient Driven Flux

This concept refers to the net flow of gas molecules resulting from a pressure difference along the pipe. Under a pressure gradient, molecules move from regions of higher pressure to regions of lower pressure. In the free molecular flow regime, the flux can be estimated using kinetic theory by considering the molecular speeds and the probability of gas molecules traversing the pipe in response to the applied gradient.

Pump-Down Time Calculation

This is the process of determining how long it takes to reduce the pressure in a container to a desired level by calculating the net flux of gas being removed. In the context of low-pressure systems with free molecular flow, the pump-down time depends on parameters like the volume of the container, the conductance of the connected piping, and the initial and final pressures, and is typically derived by integrating the rate of pressure drop over time.

Free Molecular Flow

This concept describes the regime of gas dynamics where the mean free path of gas molecules is much larger than the characteristic dimensions of the system (such as the diameter of the pipe). In this regime, intermolecular collisions are rare compared to collisions with the container walls, and the behavior of the gas is governed by molecular-surface interactions rather than continuum fluid dynamics.

Mean Free Path

The mean free path is the average distance traveled by a molecule between successive collisions. It plays a critical role in determining the flow regime of a gas; when the mean free path exceeds the dimensions of the confining geometry, the gas enters the free molecular flow regime, which requires different analytical treatment compared to continuum (viscous) flow.
