Consider Figure 4.12 with a white Gaussian input signal. a. Determine analytically the LP coefficients for a first-order predictor and for $H(z)=1 /\left(1-0.8 z^{-1}\right)$. b. Determine analytically the LP coefficients for a second-order predictor and for $H(z)=1+z^{-1}+z^{-2}$. Figure 4.11. Autocorrelation of a voiced speech segment. Figure 4.12. LP coefficients estimation. FIGURE CANT COPY

Consider Figure 4.12 with a white Gaussian input signal.
a. Determine analytically the LP coefficients for a first-order predictor and for $H(z)=1 /\left(1-0.8 z^{-1}\right)$.
b. Determine analytically the LP coefficients for a second-order predictor and for $H(z)=1+z^{-1}+z^{-2}$.
Figure 4.11. Autocorrelation of a voiced speech segment.
Figure 4.12. LP coefficients estimation.
FIGURE CANT COPY

Key Concepts

White Gaussian Signal

A white Gaussian signal is a random process with a constant power spectral density and normally distributed amplitude values. This type of signal has no memory (i.e., its samples are uncorrelated) and is often used as an input in analysis because its statistical properties simplify the derivation of analytical expressions for filter coefficients and system behavior.

Linear Prediction Analysis

Linear prediction analysis is a method used primarily in signal processing, especially in speech processing, to estimate future samples of a signal as a linear combination of past samples. This approach assumes that the signal can be modeled as the output of an all-pole filter driven by an excitation signal. The prediction coefficients are determined to minimize the overall prediction error, typically using the autocorrelation method or the Yule-Walker equations.

Predictor Order

The predictor order refers to the number of past signal samples used to generate the prediction. A first-order predictor uses one previous sample while a second-order predictor uses two. Increasing the predictor order generally allows for a more accurate representation of the spectral characteristics of the signal, albeit at the cost of increased computational complexity and the need for more data to reliably estimate the coefficients.

Filter Transfer Function Representations

Filter transfer function representations, such as H(z)=1/(1-0.8z?¹) for the first case or H(z)=1+z?¹+z?² for the second, describe different system responses. The first is an all-pole filter which is common in modeling speech resonances, while the second is a finite impulse response (FIR) filter that represents a different type of linear filter. Understanding these representations is crucial for linking the theoretical model of a signal to its practical implementation in linear prediction.

Autocorrelation Method and Yule-Walker Equations

The autocorrelation method involves computing the autocorrelation function of a signal, which measures similarity between samples at different separations. By applying the Yule-Walker equations, one establishes a relationship between these autocorrelation values and the linear prediction coefficients. This set of linear equations can be solved to obtain the optimal predictor coefficients, ensuring that the prediction error is minimized in the least-squares sense.
