Consider the Linde process for nitrogen, with parameters as in Figure 16.4. Assuming the gas leaves the cold end of the heat exchanger at $160 \mathrm{~K}$, trace the path of a small fixed mass of gas on a TS diagram such as Figure 16.3 as it passes once around the process. Estimate the heat leaving a unit mass of gas in (i) the compressor and (ii) the heat exchanger, and estimate the fraction that liquifies in the expansion.

Key Concepts

Compression and Heat Rejection

Compression raises the pressure and temperature of the gas, and in further stages, the excess heat must be rejected to return the gas to a lower temperature. Understanding the energy balance during compression – including the heat removed in the compressor – is crucial in assessing the overall efficiency of the process and the work input required.

Heat Exchanger

A heat exchanger is a device designed to transfer thermal energy between two or more fluids at different temperatures without mixing them. In the context of gas liquefaction, the heat exchanger is used to pre-cool the compressed gas before expansion by removing heat from it, thereby enhancing the efficiency of the liquefaction process while minimizing energy losses.

Phase Change and Liquefaction Fraction

During the expansion process in the Linde cycle, a portion of the gas may condense into a liquid due to the drop in temperature and pressure. Evaluating the fraction that liquefies involves understanding the energy involved in the phase change (latent heat) and the thermodynamic conditions at the expansion stage, which are key to determining the effectiveness of the liquefaction cycle.

Temperature-Entropy (TS) Diagram

A TS diagram is a graphical representation of the thermodynamic processes that a substance undergoes. It plots temperature against entropy, allowing the visualization of process paths such as compression, cooling, expansion, and phase change. For refrigeration and liquefaction processes, the TS diagram is an essential tool to analyze energy transfers, efficiency, and the effects of irreversible processes.

Linde Process

The Linde process is a gas liquefaction method that involves compressing a gas, cooling it through heat exchange, and then allowing it to expand through a throttling device. During the expansion step, the gas experiences a Joule–Thomson effect, which, under the right conditions, causes a drop in temperature sufficient to liquefy part of the gas. This process is central in the production and handling of liquefied gases, such as nitrogen.

Joule–Thomson Expansion

The Joule–Thomson expansion is a throttling process where a gas expands from a high pressure to a lower pressure without performing external work, resulting in a temperature change under constant enthalpy conditions. This effect is exploited in gas liquefaction processes; if the inversion temperature of the gas is surpassed, a drop in temperature occurs that may lead to partial liquefaction.
