Consider the Mollier or hs chart shown in Figure 16.7. (i)...

Consider the Mollier or hs chart shown in Figure 16.7. (i) Why do the isobars get steeper at high $T$ ? Is this a universal property of Mollier charts? (ii) If the chart only showed one of $T$ or $p$ as a function of $h$ and $s$, then which would it be better to show? (iii) Use the chart to find the heat capacity at constant pressure of water at $1 \mathrm{bar}, 50^{\circ} \mathrm{C}$ and of steam at $1 \mathrm{bar}, 200^{\circ} \mathrm{C}$. Figure 16.7 can't copy

Consider the Mollier or hs chart shown in Figure 16.7.
(i) Why do the isobars get steeper at high $T$ ? Is this a universal property of Mollier charts?
(ii) If the chart only showed one of $T$ or $p$ as a function of $h$ and $s$, then which would it be better to show?
(iii) Use the chart to find the heat capacity at constant pressure of water at $1 \mathrm{bar}, 50^{\circ} \mathrm{C}$ and of steam at $1 \mathrm{bar}, 200^{\circ} \mathrm{C}$.
Figure 16.7 can't copy

Key Concepts

Mollier (h-s) Chart

The Mollier chart is a graphical representation used in thermodynamics that plots enthalpy (h) versus entropy (s). It is particularly useful in analyzing the properties and processes of fluids, such as water or steam, by illustrating various thermodynamic paths, including constant pressure (isobar) and constant temperature (isotherm) lines. This diagram allows engineers to visually interpret how state variables change during processes and to quickly estimate property values without resorting to extensive calculations.

Isobars

Isobars are lines on a thermodynamic chart that represent conditions of constant pressure. In the context of the Mollier (h-s) chart, these lines can change slope depending on the temperature regime because the thermodynamic relationships between enthalpy, entropy, and temperature vary with operating conditions. The behavior of isobars, such as their steepening at higher temperatures, provides insight into the changing sensitivity of the enthalpy to temperature changes under constant pressure conditions.

Heat Capacity at Constant Pressure

Heat capacity at constant pressure (C?) is a thermodynamic property that quantifies the amount of heat required to raise the temperature of a substance by one degree while keeping the pressure constant. It is mathematically defined as the partial derivative of enthalpy with respect to temperature at constant pressure. On a Mollier chart, this property is related to the slope of the process curve along an isobar, and by analyzing this slope, one can estimate the value of C? for a given substance at specific conditions.

Graphical Analysis of Thermodynamic Diagrams

Graphical analysis using thermodynamic diagrams, such as the Mollier chart, is a method to interpret and extract engineering data visually. It leverages the relationships between key thermodynamic properties to estimate state variables and process parameters such as temperature, pressure, and heat capacity. This technique is especially valuable in practical engineering applications where quick approximations are needed, as it simplifies complex thermodynamic calculations by using the inherent geometry and slopes of the plotted curves.
