Consider the plane-wall diffuser shown in Fig. P9.71. First, assume the fluid is inviscid. Describe the flow pattern, including the pressure distribution, as the diffuser angle $\phi$ is increased from zero degrees (parallel walls). Second, modify your description to allow for boundary layer effects. Which fluid (inviscid or viscous) will generally have the highest exit pressure?

Key Concepts

Flow Separation in Viscous Fluids

Flow separation occurs when the boundary layer detaches from the surface, often due to an adverse pressure gradient, which is common in diffusers with large divergence angles. This separation causes losses in total pressure and disrupts the idealized streamlined flow assumed in inviscid analysis. Recognizing the conditions under which separation happens is vital for designing diffusers that maintain efficient pressure recovery.

Boundary Layer Effects

Boundary layer theory deals with the thin region adjacent to solid surfaces where viscous effects are significant. In diffusers, the development of a boundary layer alters the effective flow cross-section and can lead to non-uniform velocity profiles. Understanding the behavior and growth of the boundary layer is essential for predicting flow separation and overall performance when viscosity is taken into account.

Comparison of Exit Pressures

The comparison of exit pressures between inviscid and viscous flows is important in diffuser performance evaluation. Inviscid flow, which assumes no energy loss due to friction or separation, typically predicts higher exit pressures compared to viscous flow where boundary layer effects and possible separation lead to energy dissipation, reducing the achievable static pressure at the exit.

Inviscid Flow Analysis

Inviscid flow analysis involves studying fluid motion under the assumption that viscosity is negligible. This simplifies the governing equations (such as the Euler equations) and allows for the application of Bernoulli’s principle along streamlines. In diffusers, as the angle increases from parallel walls, streamlines become curved and spread apart, leading to changes in velocity and pressure without the energy dissipation associated with viscous effects.

Plane-Wall Diffuser Geometry

This concept refers to the design and characteristics of a diffuser with two flat walls that diverge at a specified angle. In the overall subject of fluid mechanics, understanding the geometry of diffusers is crucial because it significantly impacts how the fluid flows, how the velocity field develops, and how the pressure is distributed along the device.

Pressure Distribution in Diffusers

Pressure distribution in diffusers is a key aspect of fluid flow analysis, particularly within the framework of Bernoulli's principle for inviscid fluids. As the fluid decelerates in the diffuser due to greater cross-sectional area, the static pressure increases. The geometry of the diffuser, especially the angle of divergence, controls how smoothly and effectively this conversion from kinetic energy to pressure energy occurs.
