* * Design two experiments to determine the mass of a ruler,...

$* *$ Design two experiments to determine the mass of a ruler, using different methods. Your available materials are the ruler, a spring, and a set of objects of standard mass: 50 $\mathrm{g}$ , $100 \mathrm{g},$ and 200 $\mathrm{g}$ . One of the methods should involve your knowledge of static equilibrium. After you design and perform the experiment, decide whether the two methods give you the same or different results.

Key Concepts

Calibration with Standard Masses

Calibration involves using objects with known mass to establish a reliable measurement system, such as determining the spring constant in a spring-based experiment or balancing a lever. By comparing the response of the measuring system to standard masses, one creates a reference that can be used to determine unknown masses accurately. This technique ensures consistency and accuracy in experimental results.

Hooke's Law

Hooke's Law states that the extension or compression of a spring is directly proportional to the applied force, as long as the elastic limit is not exceeded. This relationship, expressed as F = kx (where F is the force, k is the spring constant, and x is the displacement), enables the measurement of forces through observed spring deformations. In mass determination, calibrating the spring with known masses allows the unknown mass to be inferred from the amount of spring extension.

Static Equilibrium

Static equilibrium is the condition of a body when all the forces and torques acting on it cancel each other out, meaning the net force and the net torque are both zero. This concept is fundamental when designing experiments involving balance and lever systems, as it ensures that an object remains at rest. It is particularly useful in determining unknown masses by setting up situations where the moments about a pivot are balanced.

Torque and Lever Arms

Torque is the rotational equivalent of force and is calculated as the product of the force and the perpendicular distance from the pivot point, known as the lever arm. In experiments using balance methods, analyzing torque is crucial because it allows one to relate the forces (including weights) applied at different distances from the pivot, thus enabling the determination of an unknown mass based on the equilibrium condition.

Transcript

00:01 We're asked to design two experiments determine a mass of a ruler using different methods.

00:07 We have available the ruler, a spring, and a set of objects of standard mass 50 grams, 100 grams, and 200 grams.

00:17 And so we want to come up with two ways.

00:23 Obviously there's probably more, but here's two ways that i considered.

00:28 First is using the spring, we could hang a 50 gram mass weight from the spring and see how far it stretches.

00:42 And then we could hang a 100 gram weight from the spring and see how far it stretches.

00:50 And using these two data points, we could get a rough estimate.

00:54 We could also use the 200 gram mass and hang it.

00:58 And we could get three values for what the spring constant is, and then we could get an average of what the spring constant is.

01:06 If it's a linear spring, then the three values we get should all be the same, but they'll probably be slightly different.

01:14 And depending on how much the ruler weighs, we could actually use one of the value that's closest to what we think the ruler ways once we back it out.

01:28 So if we hang the ruler now from the spring, it stretches at some length delta l, and since we know we can measure that, and we know this from our little experiments over here, we can figure out the mass of the ruler is the spring constant times the change in length of the spring, times divided by the gravitational constant.

01:56 So that's one way of getting the mass of the ruler using the spring.

02:04 Now we could also use pivot point...
