Determine the distance y̅ to the centroid of the area and then calculate the moments of inertia

Determine the distance y̅ to the centroid of the area and...

Key Concepts

Moment of Inertia of an Area

The moment of inertia, also known as the second moment of area, measures the distribution of an area’s shape with respect to an axis. It is a key concept in structural engineering as it indicates how resistant an area is to bending. For any given area, the moment of inertia is calculated based on the distance of each differential area element from the axis of interest, typically using integration or by summing up contributions from composite shapes.

Parallel Axis Theorem

The parallel axis theorem is used to relate the moment of inertia of an area about an axis through its centroid to the moment of inertia about any parallel axis. This theorem is particularly useful in composite area analysis, where the moments of inertia of individual shapes are first calculated about their own centroids, and then adjusted to a common reference axis. This adjustment is necessary when combining the contributions of multiple shapes whose centroids do not coincide with the overall centroid.

Centroid Calculation

This concept involves finding the geometric center of an area, which represents the average location of all the points in that area. In applications such as cross-sectional analysis, the centroid is determined either by integration or by decomposing the area into simpler geometric shapes, calculating each of their centroids, and then using the area-weighted average. The location of the centroid is crucial for many structural calculations, including the determination of moments of inertia about centroidal axes.

Composite Areas Method

When dealing with irregular or composite shapes, the overall area can be divided into simpler shapes whose centroids and moments of inertia are known or easier to calculate. By summing the contributions of each simple shape, while properly accounting for their positions relative to a reference axis (using the parallel axis theorem if necessary), one can accurately determine properties like the overall centroid and moment of inertia.

Transcript

00:01 Hi everyone here we have to find centroid y of the given area and then calculate moment of inertia i u and iv for the channels cross -section area.

00:21 Let us see here centroid y can be defined as summation of a into viver upon summation of a so it consists of three sections i am marking here this is the section 1, 2 and 3.

01:12 300 into 10 into 5 plus 2 times 50 into 10 into 35 divided by 300 into 10 to 50 into that is 12 .5 millimeter.

01:35 This is the answer of first part.

01:37 Now we have to solve for second.

01:40 We will find moment of inertia along x -axis and y -axis by applying the parallel x -s theorem so according to parallel axis theorem we can write i x to be i per x just a moment according to parallelism momentum of inertia about x -axis will be moment of inertia about centroid plus m into d square so we have to apply this concept moment of inertia about x axis of the given area would be 1 by 12 into 300 10 kukub plus 300 into 300 10 into 50 cube plus 10 into 50 into 35 minus 12 .5 whole square.

03:09 So on solving it you will get 9083 into 10 to the power 6 millimeter to the power 4.

03:20 Similarly, along y -axis you will get 1 by 12 10 into 300.

03:29 8 cube plus 2 into 1 by 12 into 50 into 10 kha cube minus sorry plus 5 into 10 into 150 into 150 minus 5 square so on solving it iy you will get 43 .53 into 10 to over 6 millimeter to the power 4 area is symmetrical to the x and y x x x that's why i x y is 0 because area is symmetrical to x and y x so moment of inertia about u can be defined as i x plus i y upon 2 i x minus i y upon 2 cause of 2 minus i x by sine of 2 theta.

05:04 Substitute the value...
