Question
Determine the overall efficiency of a motor that delivers 2 hp to a load if it draws 7.5 amperes when connected to a 240-volt supply. ______________________________________________________________________________________________________________________________________________________________
Step 1
Since 1 hp is equal to 746 watts, we calculate: \[ 2 \, \text{hp} \times 746 \, \text{W/hp} = 1492 \, \text{W} \] Show more…
Show all steps
Your feedback will help us improve your experience
Ghazala Khan and 98 other educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
An electric motor is rated at 1.5 horsepower. A test says that its efficiency is 72%. If you connect the motor to a 120 V outlet, how much current flows through it during the operation?
A hoist motor supplied by a $240-\mathrm{V}$ source requires $12.0 \mathrm{~A}$ to lift an $800-\mathrm{kg}$ load at a rate of $9.00 \mathrm{~m} / \mathrm{min}$. Determine the power input to the motor and the power output, both in horsepower, and the overall efficiency of the system. $$ \begin{array}{l} \text { Power input }=I V=(12.0 \mathrm{~A})(240 \mathrm{~V})=2880 \mathrm{~W}=(2.88 \mathrm{~kW})(1.34 \mathrm{hp} / \mathrm{kW})=3.86 \mathrm{hp} \\ \text { Power output }=F v=(800 \times 9.81 \mathrm{~N})\left(\frac{9.00 \mathrm{~m}}{\min }\right)\left(\frac{1.00 \mathrm{~min}}{60.0 \mathrm{~s}}\right)\left(\frac{1.00 \mathrm{hp}}{746 \mathrm{~J} / \mathrm{s}}\right)=1.58 \mathrm{hp} \\ \text { Efficiency }=\frac{1.58 \text { hpoutput }}{3.86 \mathrm{hp} \text { input }}=0.408=40.8 \% \end{array} $$
A hoist motor supplied by a 240-V source requires $12.0$ A to lift an 800 -kg load at a rate of $9.00 \mathrm{~m} / \mathrm{min}$. Determine the power input to the motor and the power output, both in horsepower, and the overall efficiency of the system.
