Determine the weight and cost of prepreg required to produce a hollow composite tube (outside diameter $=50 \mathrm{~mm}$, wall thickness $=5 \mathrm{~mm}$, and length $=4 \mathrm{~m}$ ) if it contains $60 \mathrm{vol} \%$ AS-4 carbon fibers (at $\$ 60 / \mathrm{kg}$ ) in an epoxy matrix (at $\$ 8 / \mathrm{kg}$ ). The tube is manufactured by wrapping the prepreg around a mandrel, and the cost of prepregging is $\$ 70 / \mathrm{kg}$.

Key Concepts

Geometric Analysis of Hollow Structures

In composite manufacturing, geometric analysis involves calculating the volume of the composite material based on the dimensions and shape of the part, such as a hollow tube. This is essential for determining the amount of material needed, which directly influences weight and cost estimations.

Cost Estimation in Composite Manufacturing

Cost estimation combines the material costs per unit weight with the calculated weight of the composite part, as well as any additional manufacturing costs. This process involves converting volumes to weights using material densities, and then applying cost rates for different components like fibers and resin, plus labor or process-specific costs, to determine the overall expense.

Volume Fractions

Volume fraction is a parameter used to denote the proportion of a particular constituent in a composite by volume. In composite design, it is critical for determining the relative amounts of reinforcement and matrix materials, and converting volume fractions into weight fractions requires knowledge of the densities of each constituent, influencing the overall material properties and cost estimation.

Prepreg

Prepreg refers to pre-impregnated fiber materials in which reinforcement fibers are pre-coated with a resin matrix. This allows for more precise fiber alignment and consistent resin content, improves handling, and facilitates later curing processes, making it popular in advanced composite manufacturing.

Composite Materials

Composite materials are engineered by combining two or more different constituents that retain their individual properties while contributing to the performance of the whole. In manufacturing, composites typically involve reinforcement fibers embedded in a matrix material, creating a structure that combines the strength of the fibers with the binding and environmental resistance properties of the matrix.
