Devise an algorithm for displaying thick polylines with a miter join, a round join, or a bevel j

step 1 In this lesson, in this lesson using algorithm to find the shortest distance between two points,

Devise an algorithm for displaying thick polylines with a...

Key Concepts

Polyline Rendering

This concept covers the methods used to display lines that have a noticeable thickness, rather than being infinitely thin. It involves calculating and drawing the additional geometry required to correctly visualize a line with width, such as offsetting the central line path and defining the boundaries of the thick line.

Stroke Joins

Stroke joins determine how the junctions between connected segments of a polyline are rendered. Different join styles affect the appearance at the corners where the segments meet, influencing visual characteristics like sharpness, smoothness, or truncation at the point of connection.

Miter Join

A miter join extends the outer edges of the thick polyline until they intersect, forming a pointed corner. This technique maintains a clean and sharp appearance at the join, but care must be taken to limit excessively long miters when the joining angle is very small.

Round Join

A round join rounds off the corner at the intersection of two thick polyline segments by adding a circular arc between the two outer edges. This technique smooths the transition between segments, creating a more aesthetically pleasing rounded corner.

Bevel Join

A bevel join simplifies the appearance of the corner by cutting off the sharp point where two polyline segments meet. It creates a flattened, diagonal surface at the join, which can improve rendering performance and create a less pointed appearance.
