Draw a reaction energy diagram for an endothermic process. Mark the positions of reactants, products, and activated complex. Indicate the activation energies of the forward and reverse processes and explain how $\Delta E$ for the reaction can be calculated from the diagram.

Key Concepts

Reaction Energy Diagram

A reaction energy diagram is a graphical representation of the energy changes during a chemical reaction. It shows the progress of the reaction along a reaction coordinate, typically depicting the potential energy of the reactants as they transform into products. This diagram helps visualize the energy barriers that must be overcome during the reaction and the relative stabilities of reactants, intermediates, and products.

Endothermic Process

An endothermic reaction is one in which energy is absorbed from the surroundings, resulting in products that are at a higher energy level than the reactants. In the context of a reaction energy diagram, the product energy level will be higher than the reactant energy level, and the difference between these levels represents the energy input required for the reaction.

Activated Complex

The activated complex, also known as the transition state, is a high-energy, unstable configuration of atoms that exists momentarily during the transformation of reactants to products. On an energy diagram, it is represented by the peak of the energy curve, indicating the maximum energy that must be overcome to proceed from reactants to products.

Activation Energy

Activation energy is the minimum energy required to convert reactants into the activated complex (transition state). There are distinct activation energies for the forward reaction (energy needed from reactants to reach the transition state) and the reverse reaction (energy needed from products to reach the transition state). These values that appear on a reaction energy diagram provide insights into the kinetics and feasibility of the reaction.

Reaction Energy Change (?E)

The reaction energy change, denoted as ?E, is the overall difference in energy between the reactants and products. In a reaction energy diagram, it can be calculated by subtracting the energy level of the reactants from that of the products. In the case of an endothermic reaction, ?E is positive, indicating an absorption of energy.
