Draw a structure for each alkane. a. 3-ethylhexane b. 3-ethyl-3-methylpentane c. 2,3-dimethylbut

step 1 So here the question is to draw a structure of each LK. Now whenever such kind of question is co

Draw a structure for each alkane. a. 3-ethylhexane b....

Key Concepts

IUPAC Nomenclature

IUPAC nomenclature is a standardized method for naming organic compounds. For alkanes, it involves identifying the longest continuous carbon chain, numbering the chain to assign the lowest possible numbers to substituent groups, and listing the substituents in alphabetical order. This system ensures that each molecule has a unique and systematic name.

Structural Representation of Organic Molecules

Drawing the structure of an organic molecule based on its name requires translating the IUPAC name into a diagram that accurately represents the carbon skeleton and the placement of any substituent groups. The process includes identifying the main carbon chain and correctly attaching and positioning the substituents according to their designated carbon numbers.

Alkanes and Branching

Alkanes are saturated hydrocarbons that contain only single bonds between carbon atoms. When branching occurs, additional alkyl groups such as methyl or ethyl groups are attached to the main chain. The presence and location of these branches affect the molecule's structure and properties, and must be accurately depicted in structural drawings.

Transcript

00:06 So here the question is to draw a structure of each lk.

00:13 Now whenever such kind of question is coming, first of all you have to take care of three points only, three steps.

00:20 First is try to understand what is the basic carbon chain.

00:25 And after that, at which position of the carbon chain, different groups or different side chains are present.

00:34 And third and very important step is that remaining hydrogen atoms you have to put to each carbon atom in the chain so and by taking care of carbon balancing.

00:49 So first of all we are solving the first one.

00:53 A, three ethyl hexane you have to draw.

00:57 Here the basic chain is hexane.

01:00 So hexane that means six carbon atoms are in.

01:05 In one chain.

01:07 So you are drawing 1, 2, 3, 4, 5 and 6 carbon atoms in a chain.

01:17 After that at the third position, ethyl group is present.

01:21 So at the third position you are putting the ethyl group, c2h5.

01:29 And then remaining hydrogen you have to put.

01:33 Now taking care of the carbon valency.

01:35 Carbon is everywhere.

01:36 Tetravalent.

01:38 So, one valency is already present here.

01:41 Remaining three valencies of carbon, this carbon is satisfied by three hydrosons.

01:48 Here carbon two valencies, so only two hydrogens will be required.

01:55 Here carbon three valency, so only one hydrogen is needed and here carbon is having two valencies two more, two more hydrogen here also and three hydrogen will be required here.

02:12 So this is the structure of your first compound that is a compound...
