During a filament winding operation, T-300 carbon fiber tows containing 6000 filaments per tow are pulled over a set of guide rollers $6 \mathrm{~mm}$ in diameter. The mean tensile strength of the filaments is $3000 \mathrm{MPa}$, and the standard deviation is $865 \mathrm{MPa}$ (assuming a standard normal distribution for filament strength). Determine the percentage of filaments that may snap as the tows are pulled over the rollers. The fiber modulus is $345 \mathrm{GPa}$, and the filament diameter is $7 \mu \mathrm{m}$.

Key Concepts

Normal Distribution and Probability Analysis

Using the normal distribution for material properties like tensile strength allows engineers to perform statistical analyses to predict failure probabilities. By comparing the induced stress to the mean strength and considering the standard deviation, one can compute a z-score that quantifies how many standard deviations the applied stress is below or above the mean. This z-score is then used to determine the percentage of filaments likely to fail, providing a probabilistic assessment of material performance under stress.

Modulus of Elasticity

The modulus of elasticity, or Young’s modulus, is a fundamental mechanical property that quantifies a material's stiffness. It relates the applied stress to the resulting strain under elastic deformation. In the context of fibers undergoing bending, the modulus is used to calculate the induced stress from a given amount of bending strain, thereby contributing to the assessment of whether the fiber will snap.

Tensile Strength Distribution

This concept involves understanding that individual fibers or filaments exhibit variability in strength, which can be characterized by a statistical distribution. In many engineering applications, a normal (Gaussian) distribution is assumed to describe the spread of tensile strengths around a mean value with a given standard deviation. This allows engineers to estimate the probability that any given filament may fail under a specified load.

Bending Stress in Fibers

When a fiber is bent over a curved surface such as a roller, it experiences bending stresses that depend on the fiber’s material properties, its geometry, and the curvature of the roller. The maximum stress induced by bending is related to the fiber’s modulus and the ratio of its radius to the radius of curvature of the roller. This bending stress can be critical when compared to the tensile strength of the fiber to determine the risk of failure.
