Each of the three steel bars is subjected to a torque as shown. Knowing that the allowable shearing stress is $8 \mathrm{ksi}$ and that $b=1.4$ in., determine the maximum torque $\mathbf{T}$ that can be applied to each bar.

Key Concepts

Allowable Stress and Safety Design

Allowable stress is the maximum stress that a material is permitted to experience under service conditions without risking failure. In the context of torsion, comparing the calculated shear stresses with the allowable value ensures that the design maintains structural integrity and safety under the applied loads.

Geometric Properties in Torsion Analysis

The geometry of a member, including its dimensions and shape, plays a critical role in torsion analysis. Cross-sectional properties such as the polar moment of inertia significantly influence how the applied torque translates into shear stresses. Understanding how these properties interact with applied loads is essential for the proper design and analysis of torsional elements.

Torsion

Torsion is the twisting of a structural member due to an applied torque. It involves understanding how the twisting moment is distributed along the member’s length and how it induces shear stresses within its material. This concept is fundamental when analyzing the response of bars, shafts, and other components subjected to rotational forces.

Shear Stress in Torsion

Shear stress in torsion describes the internal stresses that develop in a material’s cross-section as it twists. It is typically calculated using relationships that involve the applied torque, the geometric properties (like the polar moment of inertia), and the distance from the neutral axis, enabling engineers to assess whether the material will withstand the applied loads.
