Explain the following relationships: ΔG and w, cell potential and w, cell potential and ΔG, cell

step 1 The relationship between delta G and work is delta G is typically thought of as the maximum amou

Explain the following relationships: ΔG and w, cell...

Explain the following relationships: $\Delta G$ and $w$, cell potential and $w$, cell potential and $\Delta G$, cell potential and $Q .$ Using these relationships, explain how you could make a cell in which both electrodes are the same metal and both solutions contain the same compound, but at different concentrations. Why does such a cell run spontaneously?

Key Concepts

Gibbs Free Energy (?G)

Gibbs free energy quantifies the maximum reversible work that can be performed by a system at constant temperature and pressure, excluding expansion work. In electrochemistry, a negative ?G indicates a spontaneous process, and it directly relates to the electrical energy that can be generated in a cell. The equation ?G = -nFE_cell establishes that the change in Gibbs free energy is directly proportional to the cell potential, where n represents the number of moles of electrons transferred and F is Faraday’s constant.

Electrical Work and Cell Potential

The relationship between cell potential (E_cell) and electrical work is defined by the equation w = -nF E_cell. This means that the work performed by the cell, as electrical energy, is the product of the transferred charge (nF) and the cell potential, with the negative sign signifying that work is done by the system when the cell operates spontaneously. This fundamental relationship links the macroscopic measurable voltage of a battery or electrochemical cell to the microscopic thermodynamic driving force.

Nernst Equation and Reaction Quotient (Q)

The Nernst equation provides a relationship between the cell potential, the standard cell potential (E°), temperature, and the reaction quotient (Q) that reflects the relative amounts of chemical species present. It is expressed as E_cell = E° - (RT/nF) ln Q, where R is the gas constant and T is the absolute temperature. This equation allows for the calculation of cell potential under non-standard conditions by accounting for deviations in concentrations from those used to define E°.

Concentration Cells

A concentration cell is an electrochemical cell where both electrodes are composed of the same material and are immersed in identical solutions, but at different concentrations. The potential difference arises solely due to the concentration gradient, which generates a non-equilibrium reaction quotient (Q) in the Nernst equation, thereby driving the flow of electrons from one electrode to the other. This gradient creates a spontaneous cell reaction, as the system seeks to balance the concentrations, resulting in a measurable cell potential and the generation of electrical work.
