Figure 12.70 displays a three-phase delta-connected motor load which is connected to a line voltage of $440 \mathrm{V}$ and draws $4 \mathrm{kVA}$ at a power factor of 72 percent lagging. In addition, a single $1.8 \mathrm{kVAR}$ capacitor is connected between lines $a$ and $b$, while a 800 -W lighting load is connected between line $c$ and neutral. Assuming the $a b c$ sequence and taking $\mathbf{V}_{a n}=V_{p} / 0^{\circ},$ find the magnitude and phase angle of currents $\mathbf{I}_{a}, \mathbf{I}_{b}, \mathbf{I}_{c},$ and $\mathbf{I}_{n}$

Key Concepts

Three-Phase Circuit Analysis

Three-phase circuit analysis involves studying circuits with three separate phases that typically have equal magnitude voltages separated by 120° phase angles. In such systems, loads may be connected in different configurations (delta or wye), and analysis often requires converting between phase and line quantities. This concept is crucial for understanding power distribution, load balancing, and determining current and voltage relationships in industrial and commercial applications.

Delta-Connected Loads

Delta-connected loads are arranged in a closed loop such that each phase of the load is connected between two lines. This configuration has unique relationships where the line voltage equals the phase voltage; however, the line current is ?3 times the phase current with an additional 30° phase shift. Recognizing these properties is essential for correctly calculating the motor currents and understanding the impact of balanced or unbalanced load conditions in a three-phase system.

Power Factor and Complex Power

Power factor is the cosine of the phase angle between the voltage and current, and it indicates the efficiency with which a load converts electric power into useful work. Complex power combines real (active) and reactive power into a single vector representation (S = P + jQ), usually expressed in units of kVA for three-phase systems. This concept enables the analysis of systems with both resistive and reactive elements, allowing power engineers to determine the phase relationships and magnitude of currents drawn by various loads.

Reactive Power Compensation with Capacitors

Capacitors in AC circuits provide reactive power compensation by supplying leading reactive currents that counterbalance the lagging reactive currents typically drawn by inductive loads. This compensation improves the overall power factor of the system and helps reduce losses. In a three-phase network, a capacitor connected between two phases affects only those phases by injecting reactive current, thereby altering the phase currents and requiring careful analysis in unbalanced load situations.

Phasor Representation and Unbalanced Load Analysis

Phasor representation is a method of expressing sinusoidal functions as complex numbers in polar form, encapsulating both magnitude and phase angle. This technique simplifies the analysis of AC circuits, especially when dealing with multiple loads with different phase relationships. When loads are unbalanced, such as in systems with a combination of delta-connected motors, capacitor banks, and single-phase loads, each phase must be analyzed individually using phasors to accurately determine the magnitude and phase angle of currents in each branch.

Transcript

00:01 Hello everyone, let us do the following question.

00:03 Here we have a three -phase delta -connected motor load which is connected to the line voltage of 440 and rose 4 kilowatt ampere at a power factor of 72 % lagging.

00:12 In addition, a single 1 .8 -kilbar capacity is connected.

00:16 We have to find the magnitude of the current.

00:19 Here we have to find the value for magnitude of the current.

00:25 Here we will write we first find the we first find the magnitude of various current we first find the magnitude of various current magnitude of various current here we will firstly solve for the motor we will solve for the motor this is i l under the root 3 into vl this is s 4 ,000 s is 4 ,000 4 ,000 under the root 3 this is 5.

01:05 This is written as 5 .28 ampere.

01:12 Next we will solve for the capacitor.

01:17 Next we will solve for the capacitor i .c.

01:21 Qc by vn.

01:23 This is 1800 by 440.

01:26 This is 4 .091amper.

01:30 Next we will solve for the capacitor.

01:31 Next we will solve for.

01:32 For the lightning next we will solve for the lightning we have vp 440 under the root 3 this is 254 this is 254 ampere next we will write i -lpp l -i by vp this will equal to 800 by 254 this is 3 .15 amphear now we will consider the circuit this is the circuit simplest structure diagram if we'll write if voltage of a and vp is equals to 0 degree voltage of ab under the root 3 vp into 30 degrees voltage of c n vp into 120 degree and i c voltage of a b voltage of ab minus j xc this is 4 .091 into 120 degree.

02:36 Next, if we have to find the value for i1...
