FIGURE 14 Two lenses, A and B, used in combination, Example...

FIGURE 14 Two lenses, A and B, used in combination, Example 5 of "Lenses and Optical Instruments." The small numbers refer to the easily drawn rays. (II) A diverging lens with a focal length of $-14 \mathrm{cm}$ is placed 12 $\mathrm{cm}$ to the right of a converging lens with a focal length of 18 $\mathrm{cm} .$ An object is placed 33 $\mathrm{cm}$ to the left of theconverging lens. (a) Where will the final image be located? (b) Where will the image be if the diverging lens is 38 $\mathrm{cm}$ from the converging lens?

Key Concepts

Thin Lens Equation

The thin lens equation, given by 1/f = 1/d? + 1/d?, is a fundamental relation in geometrical optics that relates the focal length of a lens to the object distance and the image distance. This equation is essential for predicting how lenses form images, and it serves as the basis for solving many lens problems, including those involving combinations of lenses.

Sign Conventions

Proper application of sign conventions is crucial in optics as it determines the correct interpretation of object and image distances, as well as the focal length, particularly when dealing with converging versus diverging lenses. These conventions ensure that the correct positions and orientations of images are calculated when using the thin lens equation.

Composite Lens Systems

Composite lens systems involve multiple lenses arranged in series, where the image formed by the first lens acts as the object for the subsequent lens. Understanding this sequential process is key in analyzing how the combined effect of multiple lenses produces the final image. It requires careful attention to the distances between the lenses and the relative positions of the object and intermediate images.

Image Formation Process

The process of image formation in lens systems involves tracing rays from the object through each lens, applying the thin lens equation and sign conventions at every step. For a multi-lens setup, the image produced by the first lens becomes the object for the next lens, which may be real or virtual. This step-wise approach is essential for determining the final image’s characteristics, such as its location, orientation, and size.
