Figure 5.14 shows the velocity of an object for 0 ≤t ≤8. Calculate the following estimates of th

step 1 So we have a graph and we're using a remit sum and we can see that the graph does this. And this

Figure 5.14 shows the velocity of an object for 0 ≤t ≤8....

Figure 5.14 shows the velocity of an object for $0 \leq t \leq$ 8. Calculate the following estimates of the distance the object travels between $t=0$ and $t=8,$ and indicate whether each is an upper or lower estimate of the distance traveled. (a) A left sum with $n=2$ subdivisions (b) A right sum with $n=2$ subdivisions (FIGURE CAN'T COPY)

Figure 5.14 shows the velocity of an object for $0 \leq t \leq$
8. Calculate the following estimates of the distance the object travels between $t=0$ and $t=8,$ and indicate whether each is an upper or lower estimate of the distance traveled.
(a) A left sum with $n=2$ subdivisions
(b) A right sum with $n=2$ subdivisions
(FIGURE CAN'T COPY)

Key Concepts

Relation Between Velocity and Distance

In scenarios involving a velocity graph, the distance traveled by an object is given by the area under the velocity curve over a specific time interval. By approximating this area using Riemann sums (whether left or right), one can estimate the total distance traveled. The nature of the estimate (upper or lower) depends on both the behavior of the velocity function and the chosen method of summing.

Upper and Lower Estimates

Upper and lower estimates in the context of Riemann sums refer to approximations that provide bounds for the actual integral. An upper estimate is one that gives a value greater than the true value of the integral, whereas a lower estimate is less than the true value. This concept is particularly useful when the function is monotonic, and the choice of left or right endpoints determines the nature of the over or under estimation.

Riemann Sums

Riemann sums are a fundamental method used in calculus to approximate the area under a curve, or the integral, of a function. By subdividing the interval of interest into smaller subintervals and summing the product of function values at representative points and the subinterval width, one can estimate accumulated quantities like distance, area, or total change.

Left Riemann Sum

The left Riemann sum is a specific type of Riemann sum where the function’s value at the left endpoint of each subinterval is used to calculate each rectangular area. This method has particular estimation properties: if the function is increasing or decreasing, the left sum may provide an underestimate or overestimate respectively, depending on the function's behavior over the interval.

Right Riemann Sum

The right Riemann sum approximates an integral by evaluating the function at the right endpoint of each designated subinterval. As with the left sum, it yields varying estimation characteristics based on the function’s monotonicity within the interval, possibly meaning that it can overestimate or underestimate the actual accumulated quantity.
