Figure $6.22$ shows the tensile engineering stressstrain behavior for a steel alloy.
(a) What is the modulus of elasticity?
(b) What is the proportional limit?
(c) What is the yield strength at a strain offset of $0.002 ?$
(d) What is the tensile strength?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Tensile Strength

Tensile strength is the maximum stress that a material can withstand while being stretched before necking or failure occurs. It is the highest point on the engineering stress-strain curve and indicates the ultimate load-bearing capacity of the material.

Yield Strength at a Strain Offset

The yield strength, determined using a specified strain offset (commonly 0.002), is the stress level at which a material begins to deform plastically. This offset method provides a reproducible criterion for yielding, especially in materials that do not have a clear yield point on the stress-strain curve.

Modulus of Elasticity

The modulus of elasticity, also known as Young’s modulus, measures a material's resistance to elastic deformation under load. It is defined as the slope of the initial linear portion of the stress-strain curve, indicating how much stress is required to achieve a given amount of strain in the elastic region.

Proportional Limit

The proportional limit is the point on the stress-strain curve up to which the stress and strain are directly proportional. Beyond this limit, the material no longer behaves linearly, and Hooke's law is no longer valid, implying that the deformation may not be entirely recoverable upon unloading.
