Figure P13.11 shows a mechanism that raises packages in a transfer mechanism. If a $100-\mathrm{N}$ package sits on the horizontal link while the mechanism is stationary, determine the torque required from the motor. The weights of the links are negligible.
(FIGURE CAN'T COPY)

Key Concepts

Lever Principle

The lever principle provides a method for predicting how different forces will interact within a system based on distances from the pivot point. It explains how a small force can generate a larger torque if applied at an appropriately long moment arm, and is fundamental in the analysis and design of mechanisms that involve rotation or lifting loads.

Free-Body Diagram

A free-body diagram is a graphical representation used to isolate a body or system to visualize all external forces and moments acting upon it. This tool is critical in mechanics as it aids in setting up equilibrium equations that allow one to solve for unknown forces or torques in statically determinate or indeterminate systems.

Moment Arm

The moment arm is the perpendicular distance from the axis of rotation to the line of action of the force. It is a key factor in determining the torque generated by a force. The longer the moment arm, the more torque is produced for the same amount of force, which is a cornerstone of lever mechanics and mechanical advantage.

Torque

Torque is the rotational equivalent of linear force. It is defined as the product of the force applied and the perpendicular distance (moment arm) from the axis of rotation to the line of action of the force. In mechanical systems, calculating torque is essential for determining the amount of rotational effort needed to maintain equilibrium or drive motion.

Static Equilibrium

Static equilibrium in mechanical systems occurs when the sum of all forces and the sum of all torques (moments) about any point are zero. This principle is used to analyze structures or mechanisms that are at rest, ensuring that all applied forces and moments balance, which is crucial when determining the necessary torque to counteract applied loads.
