Figure P7.87 illustrates a three degree-of-freedom model of...

Name: Problem 87, Chapter 7: Mechanical Vibrations: Theory and Applications
Uploaded: 2026-01-23T22:54:30-08:00
Duration: 2 min 15 s
Channel: James Kiss
Description: Figure P7.87 illustrates a three degree-of-freedom model of an aircraft. A rigid fuselage is attached to two thin flexible wings. An engine is attached to each wing, but the wings themselves are of negligible mass. Derive the differential equations governing the motion of the system. (FIGURE CAN'T COPY)

Figure P7.87 illustrates a three degree-of-freedom model of an aircraft. A rigid fuselage is attached to two thin flexible wings. An engine is attached to each wing, but the wings themselves are of negligible mass. Derive the differential equations governing the motion of the system. (FIGURE CAN'T COPY)

Key Concepts

Coupled Dynamics

Coupled dynamics describes situations where multiple components or degrees of freedom of a system interact with each other, resulting in interdependent motions. In systems that combine rigid bodies and flexible components, such as an aircraft with a fuselage and wings, the motions are interconnected, leading to coupled differential equations that must be solved simultaneously to capture the complete dynamic response.

Differential Equations

Differential equations are mathematical formulations that relate a function with its derivatives, representing how the system’s variables such as positions, velocities, and accelerations evolve over time. In dynamics, they encapsulate the balance of forces and moments and are essential for analyzing the temporal behavior of mechanical systems.

Lagrangian Mechanics

Lagrangian mechanics is an analytical method used to derive the equations of motion by formulating the system's Lagrangian as the difference between its kinetic and potential energies. This method, via the Euler-Lagrange equations, facilitates the formulation of differential equations that govern both rigid and flexible dynamic components in a unified framework.

Degrees of Freedom

Degrees of freedom refer to the number of independent parameters needed to completely describe the configuration or state of a mechanical system. In dynamic models, each degree of freedom corresponds to an independent mode of motion, such as translation or rotation, that contributes to the overall behavior of the system.

Rigid Body Dynamics

Rigid body dynamics deals with the modeling and analysis of objects assumed to be non-deformable under load. This simplifies the equations of motion since the entire body, with its mass and inertia, moves while maintaining its shape, allowing the application of Newton’s laws or Euler’s equations to describe its motion.

Flexible Structures Modeling

Flexible structures modeling involves capturing the dynamic behavior of components that can deform under loading. Although certain parts, like thin flexible wings with negligible mass, may simplify the analysis, their flexibility can still introduce additional dynamic effects and coupling, especially when masses, such as engines, are attached to them.
