Find the diameter of a wire with a CSA of 311,000 circular...

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Cross-Sectional Area Measurement

The cross-sectional area (CSA) of a wire is an important parameter in electrical applications since it influences the wire’s current carrying capacity and resistance. Measuring the CSA in circular mils not only provides a convenient unit but also directly connects the area to the wire’s diameter, facilitating design and conversion calculations within the field of electrical engineering.

Circular Mil

A circular mil is a unit of measure for the cross-sectional area of a wire, defined as the area of a circle with a diameter of one mil (one thousandth of an inch). This unit is particularly useful in electrical engineering because it streamlines calculations involving wire sizes; since the area in circular mils is the square of the wire’s diameter (when the diameter is measured in mils), it simplifies the process of moving between diameter and area.

Relationship Between Diameter and Area

For circles, the standard area formula is A = ?d²/4, but when using circular mils, the area is defined directly as the square of the diameter in mils. This means that if the wire’s cross-sectional area is given in circular mils, the diameter (in mils) can be obtained by taking the square root of the area. This relationship is a key simplification used in determining wire dimensions without the added factors of ? or 4.
