Find the nodal displacements of the crane shown in Fig. 12.21 when a vertically downward load of $4500 \mathrm{~N}$ is applied at node $4 .$ The Young's modulus is $200 \mathrm{GPa}$ and the cross- $\mathrm{sec}-$ tional area is $13 \times 10^{-4} \mathrm{~m}^{2}$ for elements 1 and 2 and $6.5 \times 10^{-4} \mathrm{~m}^{2}$ for elements 3 and 4 .

Key Concepts

Finite Element Analysis

Finite Element Analysis (FEA) is a computational technique used to approximate solutions to complex engineering problems by subdividing a large system into smaller, simpler parts called elements. Each element is formulated with equations that describe its behavior, and together they provide an approximate solution to the overall system, such as determining displacements, stresses, or strains under various loading conditions.

Nodal Displacements

Nodal displacements refer to the movement or deformation at the nodes—the key points where elements connect—when a load is applied to a structure. In structural analysis, determining these displacements is crucial for assessing the performance and safety of the structure, ensuring that deformations remain within acceptable limits for serviceability and integrity.

Material Properties (Young's Modulus)

Young's Modulus is a fundamental material property that measures a material’s stiffness by relating stress to strain through Hooke's Law. In structural problems, it characterizes how much a material will deform under a given load, thereby influencing the overall deformation calculations and the element stiffness in the finite element model.

Cross-sectional Area

The cross-sectional area of an element is a key geometric parameter that directly affects its structural stiffness and load-carrying capacity. In the context of finite element analysis, variations in cross-sectional area between elements are taken into account to accurately model how each element responds to stress and strain, thereby influencing the computed displacements.

Stiffness Matrix Assembly

The stiffness matrix is a core concept in structural analysis, representing the relationship between applied forces and resulting displacements in a structure. By assembling the stiffness matrices of individual elements into a comprehensive global stiffness matrix, engineers can solve for the nodal displacements, ensuring that the load is properly distributed across the entire structure.
