Find the time required to heat the center of a 5 ×10 ×20 cm clay brick from 550^∘ C to 1500^∘ C

step 1 Alright, so the important thing is dimensions. We have all these figures. Dimension of the brick

Find the time required to heat the center of a 5 ×10 ×20 cm...

Find the time required to heat the center of a $5 \times 10 \times 20 \mathrm{~cm}$ clay brick from $550^{\circ} \mathrm{C}$ to $1500^{\circ} \mathrm{C}$ in a convective oven at $1700^{\circ} \mathrm{C}$. Take the heat transfer coefficient to be $100 \mathrm{~W} / \mathrm{m}^{2} \mathrm{~K}$, and $k=1.7 \mathrm{~W} / \mathrm{m} \mathrm{K}, \alpha=0.35 \times 10^{-6} \mathrm{~m}^{2} / \mathrm{s}$ for the brick.

Find the time required to heat the center of a $5 \times 10 \times 20 \mathrm{~cm}$ clay brick from
$550^{\circ} \mathrm{C}$ to $1500^{\circ} \mathrm{C}$ in a convective oven at $1700^{\circ} \mathrm{C}$. Take the heat transfer coefficient to be $100 \mathrm{~W} / \mathrm{m}^{2} \mathrm{~K}$, and $k=1.7 \mathrm{~W} / \mathrm{m} \mathrm{K}, \alpha=0.35 \times 10^{-6} \mathrm{~m}^{2} / \mathrm{s}$ for the brick.

Key Concepts

Biot Number

The Biot number is a dimensionless parameter defined as the ratio of the internal thermal resistance within a solid to the external convective thermal resistance at its surface. It helps determine whether a lumped capacitance model (assuming uniform temperature within the solid) is valid or if a more detailed spatial analysis is necessary for solving the transient heat conduction problem.

Transient Heat Conduction

Transient heat conduction involves the study of how temperature within a material changes over time due to conduction. It requires solving a time-dependent form of the heat equation, where the evolution of the temperature field is determined by the material's properties, geometry, and initial and boundary conditions.

Convection Boundary Conditions

Convection boundary conditions capture the heat transfer between a solid surface and a fluid medium (such as air in an oven) flowing over it. This is typically characterized by a heat transfer coefficient which quantifies how efficiently heat is convected away from or towards the surface, and it forms an essential part of the boundary condition in transient conduction problems.

Thermal Diffusivity

Thermal diffusivity is a material property that measures the rate at which temperature changes within a material, combining the effects of thermal conductivity, density, and specific heat capacity. It is critical in transient heat conduction as it determines how quickly a material responds to changes in its thermal environment.
