For a given area, the moments of inertia with respect to two rectangular centridal $x$ and $y$ axes are $\bar{I}_{x}=1200 \mathrm{in}^{4}$ and $\bar{I}_{y}=300 \mathrm{in}^{4}$, respectively. Knowing that, after rotating the $x$ and $y$ axes about the centroid $30^{\circ}$ counterclockwise, the moment of inertia relative to the rotated $x$ axis is $1450 \mathrm{in}^{4},$ use Mohr's circle to determine (a) the orientation of the principal axes, $(b)$ the principal centroidal moments of inertia.

Key Concepts

Moments of Inertia

The moment of inertia quantifies the distribution of an area's mass (or area, in the case of bending) relative to an axis. It indicates how resistant the area is to bending about that axis, forming the basis for understanding stress and deflection in structural elements.

Principal Axes and Principal Moments of Inertia

Principal axes are the orientations in which the product of inertia vanishes and the moments of inertia reach their extreme values, known as the principal moments. These axes simplify the structural analysis by aligning with the directions of maximum and minimum stiffness.

Inertia Transformation Equations

Inertia transformation equations describe how the moments of inertia, as well as the product of inertia, change when the coordinate axes are rotated. These equations are central to determining the principal moments and the angle at which the coordinate system should be oriented so that the product of inertia becomes zero.

Mohr's Circle for Moments of Inertia

Mohr's circle is a graphical tool used to visualize the transformation of the moments of inertia when the coordinate system is rotated. It allows one to determine both the magnitude of the principal moments and the orientation of the principal axes easily by representing the relationship between the moments of inertia and the product of inertia in a circle.

Transcript

00:01 In this problem, we're given various properties about an area, about the centroidal axes.

00:09 And we're told that the area moment about the centroidal x -axis is 1 ,200 inches to the 4th, and about the centriot of y -axis is 300 inches to the 4th, which means we can immediately get where the center of more circle is by taking the average of these 2, and that's 750 inches to the 4th.

00:30 We're also told that if we rotate the axis 30 degrees, then our new centroidal area moment about the new x -axis is 1 ,450 inches to the 4th.

00:46 So i've kind of tried to draw a more circle.

00:49 We know where the center is, and we know that if we rotate it and here 60 degrees, because 30 degrees in the axes.

00:59 So 60 degrees here we wind up with a slightly bigger area moment about the new x -axis.

01:09 We know x is bigger than y, so we know this one was x and so and i'm not sure if if i x y is negative or positive but i'm assuming it's negative and we'll figure that out.

01:26 But so we know if we rotate that.

01:29 So what we need to do is just use some geometry here.

01:35 And the geometry we have is that we know that whatever, this is the radius.

01:45 So this radius here.

01:48 So this is a total of 60 degrees, and i've called this fee here.

01:53 And so the radius times cosine of 60 minus fee.

02:03 That angle must be equal to ix bar x minus c in that distance and so we have this equation and then this one we know that the radius times cosine of this angle fee must be i bar x prime minus c so we have two equations and two unknowns we know what c is and we don't know what c is and we don't know r is and we don't know what fee is.

02:38 But we have two equations for those and we can solve them and we get that r is 709 inches to the fourth and fee is 9 .4 degrees...
