For an amplitude modulated wave, the maximum amplitude is...

For an amplitude modulated wave, the maximum amplitude is found to be $10 \mathrm{~V}$ while the minimum amplitude is found to be $2 \mathrm{~V}$. Determine the modulation index, $\mu$. What would be the value of $\mu$ if the minimum amplitude is zero volt?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Amplitude Modulation

Amplitude modulation is a technique used in communications where the amplitude of a high-frequency carrier signal is varied in proportion to the instantaneous amplitude of a lower-frequency modulating signal. This process allows for the transmission of information via changes in the carrier's amplitude, while its frequency remains constant.

Modulation Index

The modulation index is a measure of the extent of modulation applied to a carrier wave. It is defined as the ratio of the amplitude change due to the modulating signal to the amplitude of the unmodulated carrier. In practice, it can be determined from the maximum and minimum envelope amplitudes of the modulated wave, and it indicates how much the carrier amplitude deviates from its unmodulated value.

Envelope of an AM Wave

The envelope of an amplitude modulated wave refers to the smooth curve that connects the peak values of the modulated signal. This envelope directly follows the modulating signal and is critical for analyzing modulation characteristics such as the modulation index, as its maximum and minimum values determine the depth of modulation applied to the carrier.
