00:03
This is the answer to chapter 19, problem number 65, from the smith organic chemistry textbook.
00:11
And in this problem, we're asked to draw two amino acids at their neutral, positively charged, and negatively charged forms.
00:21
And we're asked which form predominates at ph 1, 6, and 11.
00:27
And then we're asked, what is the structure of each amino acid at the isoel? electric point.
00:35
Okay.
00:36
So first we're asked about methyonine, and we're told that the side chain of methyonine is ch2, ch2, s -c -c -h -3.
00:48
So to start, you can draw.
00:54
Okay, well, so we'll do a on this top line.
00:59
So we'll start with the neutral form.
01:02
And the neutral form, and the neutral form, is going to be the zwitter ion.
01:08
So we have a central carbon.
01:12
We have the carboxylic acid, which is going to be deprotonated.
01:21
We have a hydrogen on our central carbon.
01:26
Then we have the amine, which is going to be protonated in the zitter ion form.
01:33
And then we have our side chain.
01:36
The side chain here was ch2, ch2, s -c -h -3.
01:46
So that's our zwitter ion, our neutral form of this molecule.
01:51
And i'm actually going to move this over just a little bit.
01:56
There we go.
01:58
And so the positively charged version of this molecule is going to have the protonated amine but we'll also have the carboxylic acid protonated.
02:15
So here's our carboxylic acid protonated, so there's no charge there.
02:21
Here's our amine protonated.
02:25
So that's where the positive charge comes from.
02:28
And then our side chain is unaffected here.
02:32
So that's going to look exactly the same.
02:36
The negatively charged version of this molecule is going to be exactly the opposite.
02:42
So we'll have the deprotonated carboxylic acid, and then we will have the not protonated amine.
02:53
So nh2 with no positive charge on it.
02:58
Ch2, ch2, ch3...
