For each of the following metals, write the electronic...

For each of the following metals, write the electronic configuration of the atom and its $3+$ ion: (a) $\mathrm{Ru},(\mathbf{b}) \mathrm{Mo},(\mathbf{c}) \mathrm{Co} .$ Draw the crystal-field energy-level diagram for the $d$ orbitals of an octahedral complex, and show the placement of the $d$ electrons for each $3+$ ion, assuming a weak-field complex. How many unpaired electrons are there in each case?

Key Concepts

Electronic Configuration

This concept refers to the arrangement of electrons in an atom’s orbitals, following the Aufbau principle, Pauli exclusion principle, and Hund’s rule. In transition metals, electrons fill the (n-1)d and ns orbitals, and the order of filling and removal during ionization is crucial for determining chemical properties.

Ionization Process

Ionization in the context of transition metals involves the removal of electrons to form cations. When forming 3+ ions, electrons are typically removed first from the highest energy orbitals, usually the ns electrons, followed by the (n-1)d electrons, which affects the electronic configuration of the ion.

Crystal Field Theory

Crystal field theory explains the breaking of orbital degeneracy in transition metal complexes when ligands approach the central metal ion. This theory is used to understand the distribution of electrons among the split d orbitals and how different ligand strengths can modify the energy levels and electron pairing.

Octahedral d-Orbital Splitting

In an octahedral complex, the approach of six ligands causes the five d orbitals to split into two groups: the lower-energy t2g set and the higher-energy eg set. This splitting, quantified by the crystal field splitting parameter (?o), is fundamental for predicting the electronic structure and properties of the complex.

Weak-Field Complexes

Weak-field complexes are those in which the ligands produce a relatively small crystal field splitting parameter. As a result, the energy required for electron pairing in the lower-energy orbitals is greater than the energy difference between t2g and eg levels, leading to high-spin configurations where electrons remain unpaired as much as possible.

Magnetic Properties (Unpaired Electrons)

The number of unpaired electrons in a transition metal complex is a key factor that determines its magnetic properties. High-spin complexes, often resulting from weak-field ligands, have a larger number of unpaired electrons, which can be predicted by filling the split d orbitals according to Hund's rule.
