For the circuit in FIGURE P32.64 st, what are (a) the...

Key Concepts

Ohm's Law

Ohm's Law is a fundamental principle in electrical circuits that describes the relationship between voltage, current, and resistance. Expressed as V = IR, it is essential for determining unknown quantities in a circuit, such as the current through a resistor when the voltage and resistance are known.

Kirchhoff's Laws

Kirchhoff's Laws form the backbone of circuit analysis. Kirchhoff's Current Law (KCL) states that the total current entering a node must equal the total current leaving it, and Kirchhoff's Voltage Law (KVL) asserts that the sum of the voltage drops around any closed loop in a circuit must be zero. These principles guide the analysis and solution of complex circuits by ensuring energy and charge conservation.

Series and Parallel Resistor Networks

Resistors in circuits can be connected in series or parallel, which affects the overall resistance seen by the circuit. In series arrangements, resistances add directly, while in parallel configurations, the reciprocal of the total resistance is the sum of the reciprocals of the individual resistances. Understanding these configurations is crucial for simplifying circuits and accurately calculating currents and voltages.

Power Dissipation in Resistors

The power dissipated by a resistor is the rate at which it converts electrical energy into heat. This dissipation can be calculated using formulas such as P = I²R, P = V²/R, or P = IV, and is an important consideration in circuit design to ensure that components operate safely within their specified limits.

Node Voltage Analysis

Node Voltage Analysis is a systematic method used to determine the potential (voltage) at various points, or nodes, within an electrical circuit. By applying Kirchhoff's Current Law and establishing a reference (ground) node, this method simplifies the process of solving for unknown voltages and currents, especially in complex circuits with multiple branches.

Transcript

00:01 Now the first part of this question, we are given this circuit and we want to find the current through the 2 -oom resistor.

00:07 So what we can do is you can simplify this circuit by simplifying this parallel part into a single resistor.

00:17 So because it's 20 om and 5 ome, so the effective resistance 1 over 5 plus 1 over 20, then we inverse this.

00:33 And we should get a value of about 4 oms.

00:36 So it's the effective resistance of the this part parallel part of the circuit so the overall total resistance would be 4 plus 2 oms plus 4mns should give us 10 oms of the total and therefore the currents passing through the main circuit just the emf divided by the total resistance which is 10 ampiers right and so this is also the current that is passing through the 2 oom resistor now for the next part of this question we are to find what is the power dissipated by the 20 oom resistor and to actually find out what is the power we need to know the voltage across it so assuming them to be still a single resistor or 4 oms over here, assuming that they are just a 4 -oom resistor, effective resistance.

02:09 Then the voltage across this 4 -oom is equal to i times r.

02:14 In this case, the current is 10m times 4, should give us 40 volts.

02:22 So this is the potential difference across the 20 -oom as well as the 5 -oom resistor.

02:27 Using that, we can find what is the power.

02:30 Using v square over r which is just 40 square divided by 20 and we should get it to be 80 watts all right and now to find the potential at a point a is a little bit tricky but it's actually quite simple so what you want to do is from the particular point here, we know that this potential is 0 because it's grounded...
