For the network of Fig. 28, if $V_{B R}=6 \mathrm{~V}, \mathrm{~V}=40 \mathrm{~V}, R=10 \mathrm{k} \Omega, C=0.2 \mu \mathrm{F}$, and $V_{G K}$ (fir-
ing potential) $=3 \mathrm{~V}$, determine the time period between energizing the network and the turning on of the SCR.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

RC Circuit

An RC circuit is one that consists of a resistor and a capacitor, typically connected in series or parallel. It is fundamental in timing and filtering applications because the capacitor charges or discharges through the resistor in an exponential manner.

RC Time Constant

The RC time constant, defined as the product of the resistance (R) and the capacitance (C), is a critical measure of how quickly a capacitor charges or discharges in an RC circuit. A larger time constant means the capacitor charges or discharges more slowly.

Exponential Charging Equation

This equation describes how the voltage across a charging capacitor increases over time according to an exponential relationship, generally expressed as V(t) = V_final * (1 - e^(-t/RC)). It is essential for determining the time required for the capacitor voltage to reach a specific level.

SCR (Silicon Controlled Rectifier) Triggering

An SCR is a semiconductor device that remains off until its gate voltage reaches a predetermined firing threshold, at which point it switches to a conducting state. Understanding its triggering characteristics is important for designing circuits that use controlled switching events.
