Foundation walks for the basements of different commercial buildings have developed cracks. For the conditions described, indicate the probable cause of the wall crack condition. (a) Walls are concrete block construction; cracks exist along several horizontal mortar joints: wall deflects (bulges) inward near midheight. (b) Walls are concrete block construction; diagcnal cracking, or step-cracking, exists where two walls meet and form a corner. (c) Walls are poured concrete construction; diagonal cracks exist, all starting at the corners of various window openings.

Foundation walks for the basements of different commercial buildings have developed cracks. For the conditions described, indicate the probable cause of the wall crack condition.
(a) Walls are concrete block construction; cracks exist along several horizontal mortar joints: wall deflects (bulges) inward near midheight.
(b) Walls are concrete block construction; diagcnal cracking, or step-cracking, exists where two walls meet and form a corner.
(c) Walls are poured concrete construction; diagonal cracks exist, all starting at the corners of various window openings.

Key Concepts

Lateral Earth and Hydrostatic Pressure

Lateral earth pressure, often increased by hydrostatic pressure from saturated soils, exerts force against the basement walls. When these forces exceed the wall’s resisting capacity, they can cause deflection or inward bulging, which is commonly observed through cracks forming at critical stress points along the wall.

Stress Concentration at Openings

Openings in structural elements, such as window or door openings in poured concrete, create localized areas where stress is intensified. This can lead to cracking, especially when the surrounding structure is subjected to movement or load variations. The cracks typically emanate from these points due to the concentration of tensile stresses.

Differential Settlement

Differential settlement refers to the uneven movement of a building’s foundation, where various parts settle at different rates over time. This uneven settling can generate stresses in the structural elements, often resulting in diagonal or irregular cracking patterns, particularly where different structural components meet or at transitions in the building’s geometry.

Material Behavior and Construction Methods

The behavior of construction materials under load is crucial in interpreting cracking patterns. Different materials—such as concrete blocks versus poured concrete—have unique properties and responses to environmental stresses and movements. Understanding these differences helps in diagnosing issues, as cracking can indicate how the material and the construction method react to inherent loads and external pressures.
