Given the typical values of $h_{i e}=1 \mathrm{k} \Omega, h_{r e}=2 \times 10^{-4}$, and $A_{v}=-160$ for the input configuration of Fig. 185 : a. Determine $V_{o}$ in terms of $V_{i}$. b. Calculate $I_{b}$ in terms of $V_{i}$. c. Calculate $I_{b}$ if $h_{r e} V_{o}$ is ignored. d. Determine the percentage difference in $I_{b}$ using the following equation: $$ \text { difference in } I_{b}=\frac{I_{b}\left(\text { without } h_{\text {re }}\right)-I_{b}\left(\text { with } h_{\text {re }}\right)}{I_{b}\left(\text { without } h_{r e}\right)} \times 100 \% $$ e. Is it a valid approach to ignore the effects of $h_{r e} V_{o}$ for the typical values employed in this example?

Given the typical values of $h_{i e}=1 \mathrm{k} \Omega, h_{r e}=2 \times 10^{-4}$, and $A_{v}=-160$ for the input configuration of Fig. 185 :
a. Determine $V_{o}$ in terms of $V_{i}$.
b. Calculate $I_{b}$ in terms of $V_{i}$.
c. Calculate $I_{b}$ if $h_{r e} V_{o}$ is ignored.
d. Determine the percentage difference in $I_{b}$ using the following equation:
$$
\text { difference in } I_{b}=\frac{I_{b}\left(\text { without } h_{\text {re }}\right)-I_{b}\left(\text { with } h_{\text {re }}\right)}{I_{b}\left(\text { without } h_{r e}\right)} \times 100 \%
$$
e. Is it a valid approach to ignore the effects of $h_{r e} V_{o}$ for the typical values employed in this example?

Key Concepts

h-Parameters

h-parameters (hybrid parameters) are a set of linearized parameters used to model the behavior of transistors in small-signal analysis. They include values such as the input impedance (h_ie), the reverse voltage gain (h_re), and other factors that allow engineers to predict how the transistor will amplify signals in a circuit.

Small-Signal Model Analysis

The small-signal model simplifies the behavior of a transistor by linearizing its characteristics around a bias or operating point. This approach allows the analysis of signal amplification by using linear circuit techniques and h-parameters without having to deal with the full nonlinear behavior of the transistor.

Voltage Gain

Voltage gain is a measure of how much an amplifier increases the amplitude of an input voltage signal. In transistor amplifier circuits, the voltage gain is often determined by a combination of h-parameters and other circuit components, and is used to relate the output voltage to the input voltage in the small-signal model.

Base Current Calculation

Base current calculation involves determining the current entering the base of a transistor, which is crucial for understanding the operation and biasing of bipolar junction transistors (BJTs). Accurate calculation of the base current helps in analyzing the overall current amplification and the input characteristics of the amplifier circuit.

Circuit Approximation Techniques

Approximation techniques in circuit analysis involve neglecting terms or effects that have a minimal impact on the overall behavior of the circuit. In many practical cases, small parameters such as the product of h_re and V_o may be ignored to simplify calculations. However, the validity of such approximations must be verified by comparing the simplified results with more complete models.

Percentage Error Calculation

Percentage error calculation is a method used to quantify the difference between a simplified (approximated) result and the more complete, detailed calculation. This concept is critical for assessing the impact of ignoring small terms in circuit analysis and for justifying the use of approximations by demonstrating that any resultant error is within acceptable limits.
