Go to http://cst-www.nrl.navy.mil/lattice, and click on "cubic close packed," "fcc(A1)," and finally "see the structure from several perspectives." (a) Draw the top view, and indicate which atoms are in the first layer and which are in the second layer. Why is the third layer not shown? (b) Draw the front view, and indicate which atoms are in the first layer and which are in the second layer. Does the front view differ from the top view?

Go to http://cst-www.nrl.navy.mil/lattice, and click on "cubic close packed," "fcc(A1)," and finally "see the structure from several perspectives."
(a) Draw the top view, and indicate which atoms are in the first layer and which are in the second layer. Why is the third layer not shown?
(b) Draw the front view, and indicate which atoms are in the first layer and which are in the second layer. Does the front view differ from the top view?

Key Concepts

Crystallographic Projection Views

Crystallographic projection views, such as top and front views, are techniques used to visualize three-dimensional crystal structures in two dimensions. These projections help in distinguishing the positional relationships of atoms in different layers and understanding the overall symmetry of the structure. Differences or similarities between views can reveal important aspects of the atomic arrangement and the inherent stacking patterns within the material.

Close-Packed Layer Stacking

Close-packed layer stacking refers to the way atoms are arranged in successive layers to achieve maximum packing efficiency. In FCC structures, layers are typically arranged in an ABC stacking sequence where each layer is positioned in the depressions of the previous layer. This specific stacking often causes certain layers to be superimposed in certain projections, which explains why some layers, like the third layer in a top view, may not be distinguishable.

Face-Centered Cubic (FCC) Structure

The FCC structure is a type of crystal lattice where atoms are located at each of the corners and the centers of all the faces of the cube. This arrangement is known for its high packing efficiency and is a common structure in metals. It plays a crucial role in determining the material properties such as density, coordination number, and mechanical strength.
