Gupersonic airflow enters an adiabatic, constant area (inside diameter $=1 \mathrm{ft}$ ) 30 -ft-long pipe with $\mathrm{Ma}_{1}=3.0 .$ The pipe friction factor is estimated to be $0.02 .$ What ratio of pipe exit pressure to pipe inlet stagnation pressure would result in a normal shock wave standing at (a) $x=5 \mathrm{ft},$ or $(\mathbf{b}) x=10 \mathrm{ft},$ where $x$ is the distance downstream from the pipe entrance? Determine also the duct exit Mach number and sketch the temperature-entropy diagram for each situation.

Key Concepts

Normal Shock Waves

A normal shock wave is a sudden, nearly discontinuous change in the flow properties of a compressible fluid, such as pressure, temperature, and Mach number, as the flow transitions from supersonic to subsonic speeds. Understanding normal shocks is essential to analyzing high-speed flows in ducts and nozzles and predicting the associated losses in total pressure due to irreversible processes.

Supersonic Flow

Supersonic flow is characterized by flow speeds that exceed the local speed of sound, leading to unique phenomena such as shock waves, expansion fans, and significant compressibility effects. In such flows, small disturbances cannot travel upstream, which is critical when assessing the impact of shocks and friction in constant-area ducts.

Stagnation Properties

Stagnation properties refer to the flow conditions—such as stagnation pressure and temperature—that a fluid would reach if brought to rest isentropically. These properties form a baseline for analyzing energy losses and non-isentropic changes in compressible flow, especially in scenarios involving shocks or frictional effects.

Adiabatic Flow

An adiabatic flow is one in which there is no heat transfer with the surroundings. This simplification allows the application of energy conservation principles in analyzing fluid-dynamic problems. However, even in an adiabatic process, irreversible phenomena like shock waves and friction still generate entropy changes, impacting the flow's stagnation properties.

Friction in Duct Flow

Friction in duct flow, often characterized by a friction factor, represents the viscous effects that lead to energy dissipation as a fluid flows through a conduit. In compressible flows, friction alters the pressure distribution, can precondition the flow before a shock, and influences the overall stagnation pressure recovery, making its assessment crucial in duct and pipe analyses.

Temperature-Entropy Diagram

A temperature-entropy (T-s) diagram is a graphical representation of thermodynamic processes, showing how temperature and entropy change during various processes like compression, expansion, and shock waves. In the context of compressible flows and duct analyses, the T-s diagram is a useful tool to visualize the irreversible nature of shocks and friction, as well as to map out the energy state changes throughout the process.
