Hollow Sphere Suppose a charge is located at the center of a hollow sphere as shown in Fig. $24-38$. (a) Are the intersections of the field lines with the surface of the sphere uniformly distributed throughout? In other words, is the density of lines passing through the surface of the sphere uniform? Explain why or why not. (b) Consider surface elements $A$ and $B$, which have exactly the same area. Is the number of field lines passing through surface element $A$ greater than, less than, or equal to the number of field lines through surface element $B ?$ Explain. (c) Is the flux through surface element $A$ greater than, less than, or equal to the flux through surface element $B$ ? Explain.

Hollow Sphere Suppose a charge is located at the center of a hollow sphere as shown in Fig. $24-38$.
(a) Are the intersections of the field lines with the surface of the sphere uniformly distributed throughout? In other
words, is the density of lines passing through the surface of the sphere uniform? Explain why or why not.
(b) Consider surface elements $A$ and $B$, which have exactly the same area. Is the number of field lines passing through surface element $A$ greater than, less than, or equal to the number of field lines through surface element $B ?$ Explain.
(c) Is the flux through surface element $A$ greater than, less than, or equal to the flux through surface element $B$ ? Explain.

Key Concepts

Surface Element

A surface element is an infinitesimally small area on a surface over which the electric field can be integrated to calculate the total flux. In cases where the surface and the field exhibit symmetry, such as in a sphere around a central charge, equal area elements intercept equal portions of the field, leading to uniform flux distribution.

Spherical Symmetry

Spherical symmetry implies that the properties of a system, such as the electric field produced by a point charge at the center of a sphere, are the same in every direction. This symmetry guarantees that any radial surface element on a sphere will intercept the same fraction of the total flux as any other surface element of equal area.

Electric Flux

Electric flux is a measure of the number of electric field lines passing through a surface. It is computed by taking the dot product of the electric field and an elemental area over the surface. In symmetric situations, such as a point charge at the center of a sphere, the flux through surface elements of equal area is the same.

Gauss's Law

Gauss's Law states that the net electric flux through any closed surface is equal to the charge enclosed by that surface divided by the permittivity of free space. This principle is fundamental in determining how the electric field behaves around charges and simplifies the calculation of the field in systems with high symmetry.

Electric Field Lines

Electric field lines are a visual representation of the direction and magnitude of the electric field. Their density at a given point is proportional to the strength of the electric field there. In contexts of symmetric charge distributions, these lines provide intuition about how uniformly the field extends across a surface.
