If an iron bar is removed from the center of a coil, and the...

Name: Problem 10, Chapter 12: Electricity 1: Devices, Circuits and Materials
Uploaded: 2021-08-13T07:24:02-08:00
Duration: 2 min 19 s
Channel: Prabhu Ramji
Description: If an iron bar is removed from the center of a coil, and the current is held constant, what will happen to the strength of the magnetic field?

If an iron bar is removed from the center of a coil, and the current is held constant, what will happen to the strength of the magnetic field? ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________

If an iron bar is removed from the center of a coil, and the current is held constant, what will happen to the strength of the magnetic field?
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Magnetic Permeability

Magnetic permeability is a material property that indicates how easily a magnetic field can be established within a substance. Materials like iron have high permeability, which means they can concentrate and strengthen the magnetic field when used as a core in a coil.

Role of Ferromagnetic Cores in Electromagnets

Ferromagnetic cores, such as an iron bar, are used in coils to enhance the magnetic field due to their high magnetic permeability. When such a core is present, the magnetic field becomes much stronger because the material channels the magnetic flux more efficiently. Removing the core reduces the effective permeability and, consequently, the magnetic field strength.

Magnetic Field Dependence on Core Material

The strength of a magnetic field in a coil depends not only on the current and the number of windings but also on the medium within the coil. Inserting a material with high permeability boosts the field, while replacing it with a material of lower permeability (like air) diminishes the field strength even if the current remains constant.
