If the same mass flowrate of air obtained in Problem 11.49...

If the same mass flowrate of air obtained in Problem 11.49 is desired through the shortened duct of Problem $11.50,$ determine the back pressure, $p_{2},$ required. Assume $f$ remains constant at a value of 0.03

Key Concepts

Duct Geometry

Duct geometry, including factors like length and cross-sectional area, strongly influences flow characteristics and pressure losses in a system. Changes in geometric dimensions can alter the resistance to flow, requiring modifications in the applied back pressure or other parameters in order to maintain a constant mass flow rate.

Darcy–Weisbach Equation

The Darcy–Weisbach equation is used to relate the pressure drop due to friction in a duct or pipe with factors such as the flow velocity, pipe length, hydraulic diameter, and the friction factor. It provides a fundamental framework for analyzing and designing fluid flow systems, ensuring that the required mass flow rate can be maintained by adjusting parameters like back pressure.

Pressure Drop

Pressure drop refers to the decrease in pressure as a fluid flows through a duct or pipe due to frictional forces and other resistive effects. It is a key design parameter in duct and pipe systems as it affects the energy required to drive the flow, and it must be adequately managed to achieve the desired operational performance.

Mass Flow Rate

Mass flow rate is the measure of the mass of fluid (or air) passing through a given cross-sectional area per unit time. It is a fundamental parameter in fluid dynamics that determines the amount of fluid being transported in a system and is influenced by factors such as pressure, temperature, and duct geometry.

Friction Factor

The friction factor is a dimensionless quantity that quantifies the resistance due to friction along the walls of a duct or pipe. It plays a crucial role in determining the pressure losses within a system and appears in the Darcy–Weisbach equation, helping engineers predict how changes in the flow regime or duct roughness will affect the overall pressure drop.
