If the waveform shown in Figure P4.11 is the voltage across a capacitor plotted as a function of time with: $$ v_{\mathrm{PK}}=20 \mathrm{~V} \quad T=40 \mu \mathrm{~s} \quad C=680 \mathrm{nF} $$ determine and plot the waveform for the current through the capacitor as a function of time.

If the waveform shown in Figure P4.11 is the voltage across a capacitor plotted as a function of time with:

$$
v_{\mathrm{PK}}=20 \mathrm{~V} \quad T=40 \mu \mathrm{~s} \quad C=680 \mathrm{nF}
$$

determine and plot the waveform for the current through the capacitor as a function of time.

Key Concepts

Differentiation of Waveforms

In order to determine the current waveform from a given voltage waveform, one must take the derivative of the voltage with respect to time. This process identifies how the slope (or rate of change) at each point of the voltage curve translates into the magnitude and direction of the current, making differentiation a key mathematical tool in time-domain circuit analysis.

Capacitor Voltage–Current Relationship

This concept establishes that the current through a capacitor is equal to the capacitance multiplied by the time derivative of the voltage across it, expressed as i(t) = C · dv(t)/dt. It is the fundamental law that relates how fast the voltage changes over time to the instantaneous current flowing through a capacitor, and it is critical for analyzing transient behaviors in circuits.

Time-Domain Signal Analysis

This involves examining signals as functions of time, particularly their periodic attributes, amplitude variations, and sudden changes. Understanding these properties is essential when transforming one signal (voltage) into another (current) by mathematical operations like differentiation, as it provides insight into the dynamic behavior of the circuit elements over a given period.

Graphical Representation of Circuit Behavior

Plotting waveforms is a visual technique that aids comprehension of how voltage and current vary with time. Graphical representations help in identifying key features such as peaks, edges, and periodicity, and they assist in conceptualizing the physical meaning behind mathematical relationships in circuit theory.
