(II) (a) A horizontal steel I-beam of cross-sectional area 0.041 m^2 is rigidly connected to two

step 1 In our case, we have a steel rod, which is fixed in between two plates. Now, the temperature cha

(II) (a) A horizontal steel I-beam of cross-sectional area...

(II) $(a)$ A horizontal steel I-beam of cross-sectional area 0.041 $\mathrm{m}^{2}$ is rigidly connected to two vertical steel girders. If the beam was installed when the temperature was $25^{\circ} \mathrm{C},$ what stress is developed in the beam when the temperature drops to $-25^{\circ} \mathrm{C} ?(b)$ Is the ultimate strength of the steel exceeded?

Key Concepts

Coefficient of Thermal Expansion

The coefficient of thermal expansion is a material property that measures the rate at which a material expands or contracts with a change in temperature. It is crucial in calculating the free expansion or contraction of a material, and when combined with the modulus of elasticity, it helps predict the thermal stress that develops under restrained conditions.

Ultimate Strength

Ultimate strength is the maximum stress a material can withstand under loading before failure occurs. In the context of thermal stress analysis, comparing the induced stress with the ultimate strength of the material is essential to ensure that the structure remains safe and that the thermal stresses do not exceed the material's failure limit.

Constraint Effects on Thermal Strain

When a structure, such as an I-beam in a rigid framework, is prevented from freely expanding or contracting due to temperature variations, the resulting constraint induces additional stresses. This concept emphasizes that the actual strain experienced by the material deviates from its free thermal strain, resulting in self-equilibrating stresses in the structure.

Thermal Stress

Thermal stress arises in materials when temperature changes induce expansion or contraction, but the material is restrained from changing shape freely. In such cases, the internal stresses develop to counteract the imposed thermal strains, potentially leading to tension or compression within the material.

Young's Modulus

Young's modulus (or the modulus of elasticity) quantifies the stiffness of a material and defines the linear relationship between stress and strain under elastic deformation. In thermal stress calculations, it is used along with the thermal expansion coefficient to determine the magnitude of stress induced by temperature changes in a constrained structure.
