(II) A heavy load $M g=66.0 \mathrm{kN}$ hangs at point $\mathrm{E}$ of thesingle cantilever truss shown in Fig. $70 .$ (a) Use a torqueequation for the truss as a whole to determine the tension$F_{\mathrm{T}}$ in the support cable, and then determine the force $\vec{\mathbf{F}}_{\mathrm{A}}$ on the truss at pin A. (b) Determine the force in each memberof the truss. Neglect the weight. of the trusses, which issmall compared to theload.

Get the answer to your homework problem.

Try Numerade free for 7 days

Like

Report

A. $150 \mathrm{kN}$; $170 \mathrm{kN}$; $23^{\circ}$ above $\mathrm{AC}$B. $76 \mathrm{kN},$ in tension; $38 \mathrm{kN},$ in compression; $76 \mathrm{kN},$ in compression; $76 \mathrm{kN},$ in tension; $114 \mathrm{kN},$ in compression; $76 \mathrm{kN},$ in compression
