Il Is there a battery for which the 200 Ωresistor in FIGURE...

Il Is there a battery for which the $200 \Omega$ resistor in FIGURE P32.67 dissipates no power? If so, what are its emf and its orientation? That is, is the negative terminal on the top or bottom?
CAN'T COPY THE FIGURE

Key Concepts

Kirchhoff’s Voltage Law (KVL)

Kirchhoff’s Voltage Law states that the algebraic sum of all voltages in a closed loop must equal zero. This principle is used to analyze circuits by accounting for all sources of emf and voltage drops. Applying KVL can reveal conditions under which specific elements, such as a resistor, might have no net voltage across them, leading to zero current and therefore zero power dissipation.

Resistor Power Dissipation

Power dissipation in a resistor is governed by the product of the square of the current through it and its resistance (P = I²R) or alternatively by the square of the voltage across it divided by its resistance (P = V²/R). A resistor will dissipate no power if either the current flowing through it is zero or there is no voltage difference across it. Analyzing these conditions is essential when exploring circuit configurations where a resistor might be rendered effectively ‘invisible’ in terms of energy loss.

Battery Electromotive Force (EMF)

This concept refers to the potential difference generated by a battery that drives current through a circuit. It represents the energy per unit charge available to push electrons around the loop. In circuit analysis, understanding the EMF is crucial because its magnitude and sign determine the direction and magnitude of current flow, which in turn affects how other elements in the circuit behave.

Battery Orientation and Polarity

The orientation of a battery in a circuit defines which terminal is positive and which is negative. This is important because the polarity of the battery affects the net voltage on different parts of the circuit. In many cases, the arrangement of batteries or other voltage sources can be chosen to either aid or oppose each other, directly impacting whether a particular component, like a resistor, sees a voltage drop.
