In a ballistic pendulum experiment, a small marble is fired...

In a ballistic pendulum experiment, a small marble is fired into a cup attached to the end of a pendulum. If the mass of the marble is $0.00750 \mathrm{~kg}$ and the mass of the pendulum is $0.250 \mathrm{~kg}$, how high will the pendulum swing if the marble has an initial speed of $6.00 \mathrm{~m} / \mathrm{s}$ ? Assume that the mass of the pendulum is concentrated at its end. Example 7-6

Key Concepts

Ballistic Pendulum Experiment

This experimental setup is used to measure the speed of a projectile by analyzing its collision with a pendulum and the subsequent swing. It integrates the principles of momentum conservation during the collision phase and energy conservation during the swing, providing a practical application of these core concepts in mechanics.

Energy Conservation in Pendulum Motion

Once objects have collided, the kinetic energy of the combined mass converts to gravitational potential energy as the pendulum rises. By applying the conservation of mechanical energy principle, it is possible to relate the post-collision velocity of the system to the maximum height reached, thus enabling a solution through energy conversion analysis.

Inelastic Collision

An inelastic collision is one in which the colliding objects coalesce or stick together after impact. Although momentum is conserved through the collision, kinetic energy is partially transformed into other forms of energy, such as thermal or sound energy, making it a key concept in analyzing systems where the energy before and after the collision is not equal.

Conservation of Momentum

In any collision, provided that external forces are negligible or their impulses cancel, the total momentum of the system remains constant. This fundamental principle allows us to determine the post-collision velocity of objects that stick together, even when kinetic energy is not conserved, as is typical in inelastic collisions.
