In a combined heat and power (CHP) generation process, by-product heat is used for domestic or industrial heating purposes. Hot steam is carried from a CHP generation plant by a tube with diameter of $127 \mathrm{~mm}$ centered at a square crosssection solid bar made of concrete with thermal conductivity of $1.7 \mathrm{~W} / \mathrm{m} \cdot \mathrm{K}$. The surface temperature of the tube is constant at $120^{\circ} \mathrm{C}$, while the square concrete bar is exposed to air with temperature of $-5^{\circ} \mathrm{C}$ and convection heat transfer coefficient of $20 \mathrm{~W} / \mathrm{m}^{2}$. $\mathrm{K}$. If the temperature difference between the outer surface of the square concrete bar and the ambient air is to be maintained at $5^{\circ} \mathrm{C}$, determine the width of the square concrete bar and the rate of heat loss per meter length. Answers: $1.32 \mathrm{~m}, 530 \mathrm{~W} / \mathrm{m}$

Key Concepts

Steady-State Heat Transfer Analysis

Steady-state conditions assume that the temperature distribution within the system remains constant over time. This analysis simplifies the mathematical treatment of heat transfer as it allows the use of constant material properties and boundary conditions to calculate heat fluxes and temperature gradients.

Convection Heat Transfer

Convection involves the transfer of heat between a solid surface and a moving fluid, usually air or water. It is influenced by the fluid's velocity, properties, and the surface geometry, and is characterized by the convection heat transfer coefficient, which is essential in calculating the rate of heat loss to the environment.

Thermal Resistance

Thermal resistance is a measure of a material's or a system's opposition to heat flow. In steady-state heat transfer analysis, individual resistances from conduction and convection are often combined to determine the overall heat transfer and to design systems that maintain specific temperature differences.

Combined Heat and Power (CHP) Systems

CHP systems convert fuel into both electricity and useful thermal energy. The key idea is to utilize heat that is normally wasted in electrical power generation by using it for heating applications, thereby improving overall system efficiency and reducing energy losses.

Conduction Heat Transfer

This concept describes the transfer of thermal energy through a material due to a temperature gradient. In engineering applications, materials’ thermal conductivity determines how quickly heat is conducted, and it is central to designing systems where internal heat distribution is critical.
