In a p ^+ n junction diode, which side penetration depth...

In a p $^{+} n$ junction diode, which side penetration depth will be larger? Estimate and compare the ratio of the penetration depths on both sides of the junction if the acceptor concentration is twice than that for the donor concentration. Compare the generated electric fields on both sides also.

Key Concepts

Depletion Region Formation

In a pn junction diode, when p-type and n-type materials are joined together, carriers diffuse across the junction and recombine, leaving behind fixed ionized donor and acceptor atoms. This region, depleted of mobile carriers, is called the depletion region. It is crucial in establishing an internal electric field that affects the diode’s current-voltage characteristics.

Doping Concentration and Depletion Width

The extent of the depletion region on each side of the junction is inversely related to the doping concentration. A region with a lower doping level will exhibit a wider depletion zone compared to a region with a higher doping level. This relationship means that in a diode with one side more heavily doped, the lighter-doped side will have a larger penetration depth into the material.

Charge Neutrality Condition

Within the depletion region, the total charge must remain balanced. Because of charge neutrality, the product of the doping concentration and the depletion width on the p side equals that on the n side (Na · xp = Nd · xn). This principle is used to determine the ratio of the depletion widths when the doping levels are different.

Electric Field Distribution in a pn Junction

The electric field in a pn junction is generated by the separation of charge in the depletion region. Its peak value is given by the local ionized donor or acceptor concentration times the depletion width divided by the semiconductor's permittivity. As the depletion width differs on each side due to the varying doping levels, the maximum electric field may have different magnitudes on each side, even though it is continuous across the junction.
