In an R L C circuit, these three elements are connected in series: a resistor of 20.0 Ω, a 35.0-

In an R L C circuit, these three elements are connected in...

Key Concepts

AC Ohm's Law

AC Ohm's Law is an extension of the traditional Ohm's Law, incorporating complex impedance to account for both resistance and reactance in AC circuits. It states that the voltage across an element is equal to the product of the current and the impedance (V = IZ), where both voltage and current are considered as phasors. This law is pivotal for solving circuit problems involving sinusoidal sources.

Reactance

Reactance is the measure of opposition to the change in current by capacitors and inductors in an AC circuit. It is frequency-dependent, with inductive reactance given by X? = ?L and capacitive reactance by X_C = 1/(?C), where ? is the angular frequency. This concept is fundamental in understanding how different circuit elements behave under alternating current conditions.

Impedance

Impedance extends the concept of resistance to AC circuits by incorporating both resistive and reactive components. It is a complex quantity represented as Z = R + j(X? - X_C) in a series RLC circuit, where R is the resistance and j is the imaginary unit. The magnitude of impedance, |Z| = ?(R² + (X? - X_C)²), determines how much the circuit opposes the flow of AC current.

RMS Values

The root mean square (RMS) value is a statistical measure of the magnitude of a varying quantity. In AC circuits, RMS values are used to represent effective voltage and current, as they provide a means of comparing AC signals to a DC equivalent in terms of energy delivery or power.

Phase Angle

The phase angle in an AC circuit represents the angular difference between the voltage and current waveforms. It is determined by the relative sizes of the circuit’s resistive and reactive components, and it indicates whether the current waveform leads or lags behind the voltage waveform. This concept is essential for understanding power factor and energy efficiency in AC systems.

Phasor Diagrams

Phasor diagrams are graphical representations that depict the magnitude and phase relationships of sinusoidal functions, such as voltage and current in an AC circuit. By using vectors (phasors) in the complex plane, these diagrams help visualize how resistive and reactive components combine and affect the overall circuit behavior.

Transcript

00:01 When you're analyzing an ac circuit, you can use what looks like oamslaw, but instead of just resistances, you have reactants for the capacitor and the inductor that are in the circuit.

00:16 Here we have a series circuit, so what we know for sure is that there is the same current through everything.

00:25 And the way to get rid of the oscillating time dependence is to work.

00:31 In terms of amplitudes so that you don't have to worry about time, whether things are going with a cosine or oscillating like a sign.

00:43 There are two different types of amplitude, at least.

00:48 There is what's called the rms amplitude, which is the peak amplitude, which i usually call a v0 divided by the square root of 2.

00:59 It comes from averaging posines and sine squared over cycles, many cycles.

01:10 So let's figure out the equivalent of resistance.

01:14 They are called reactances, and they add together in something called impedance, which is kind of like a vector, but we call those phasers instead.

01:25 And we'll get to that.

01:26 But capacitive reactance, or xc, is a frequency dependent resistance, one over omega c is how it is calculated.

01:38 And we have both of those numbers for this particular situation, 10 to the third rads per second for the angular frequency and 50 microferidase for the capacitor.

01:54 And when combined, we get units of oms, 20 oms in this case.

02:03 The inductor has an inductive reactance that gets bigger with frequency due to faraday's law.

02:15 And again, we can calculate that out, and we get 35 oms.

02:28 We combine them together into another generalized resistance called impedance.

02:37 And that impedance is like taking the magnitude of a vector, where the resistance is like an x component, and the reactances are like the y component with a capacitive being a negative y component.

02:56 And really all that's going on there is, let's say that the voltage source is oscillating like a cosine.

03:06 And this means that the current through the resistor is also oscillating like a cosine.

03:14 But the inductive and capacitive voltages are out of phase by plus minus 90 degrees.

03:23 And so we can think about those lying along the y -axis.

03:28 That is, they oscillate like plus -minus signs instead of cosines.

03:33 And that's why this is known as a phaser representation, because it's the phase angle.

03:39 That's 90 degrees, not a physical vector, making an angle in space.

03:49 Okay, and the total impedance is 25 oms.

03:53 Now, what we can do with that is we can use these in a generalized oms law.

03:59 So i'll put that in quotes.

04:02 But it turns out that circuit laws are the same for an ase circuit, including kirchhoff's loop and junction rules, but we don't have to use those.

04:13 But the irms times the z, irms amplitude times the resistance is equal to the battery slash source voltage rms.

04:29 And so we can solve for the series current, at least its amplitude...
