In electron-beam lithography, a focused beam of electrons (produced by a scanning electron microscope) is used instead of UV light to expose photoresist. Which is capable of producing smaller features: $100 \mathrm{eV}$ electrons or $50 \mathrm{keV}$ electrons? (In practice, the resolution of electron-beam lithography is limited by aberrations in the electron optics of the electron microscope, rather than by the wavelength of the electron - the aberration-limited resolution is about $5 \mathrm{~nm}$.)

In electron-beam lithography, a focused beam of electrons (produced by a scanning electron microscope) is used instead of UV light to expose photoresist. Which is capable of producing smaller features:
$100 \mathrm{eV}$ electrons or $50 \mathrm{keV}$ electrons? (In practice, the resolution of electron-beam lithography is limited by aberrations in the electron optics of the electron microscope, rather than by the wavelength of the electron
- the aberration-limited resolution is about $5 \mathrm{~nm}$.)

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Aberration-Limited Resolution

In practical electron-beam lithography, despite the potential for high resolution due to short electron wavelengths, the actual minimal feature size is often constrained by imperfections in the electron optics system, known as aberrations. These aberrations cause distortions and limit the effective resolution to a level (around 5 nm in some cases) that may be above the theoretical diffraction limit.

Electron Wavelength and Energy Relationship

The de Broglie relation shows that the wavelength of electrons is inversely related to the square root of their kinetic energy. This means that electrons at higher energies (such as 50 keV) have shorter wavelengths compared to those at lower energies (like 100 eV), and therefore, can potentially produce finer resolution in lithographic applications.

Electron-Beam Lithography

Electron-beam lithography is a fabrication process that directly writes patterns onto a substrate using a focused electron beam. Unlike conventional photolithography which uses light, this method benefits from the shorter wavelengths of electrons, which in theory can create extremely small features and is essential in semiconductor manufacturing and nanoengineering.
